OPENFLOW COMMANDS
SHOW
OPENFLOW RULES
Related
commands
show openflow flows
show openflow coverage
Command
changes
Version 5.4.6-1.1: command added
Version 5.4.7-1.1: command added to GS900MX, XS900MX, x550 series products
Version 5.4.7-2.1: command added to IE300, IE500 series products
Version 5.4.8-0.2: added to SBx908 GEN2
Version 5.4.8-1.1: added to IE210L series products
table_id=2, duration=14s, n_packets=0, n_bytes=0,
priority=97,actions=output:1table_id=2, duration=14s, n_packets=0,
n_bytes=0, priority=0,actions=drop

table_id=3, duration=14s, n_packets=0, n_bytes=0,
priority=0,actions=drop

table_id=254, duration=85668s, n_packets=0, n_bytes=0,
priority=2,recirc_id=0,actions=drop

table_id=254, duration=85668s, n_packets=736, n_bytes=144050,
priority=0,reg0=0x1,actions=controller(reason=no_match)

table_id=254, duration=85668s, n_packets=19, n_bytes=5668,
priority=0,reg0=0x2,actions=drop
Table 52-4: Parameters in the output from show openflow rules
Parameter Description
duration The duration of the flow entry in seconds
n_packets The number of packets that match the flow entry
n_bytes The number of bytes that match the flow entry
priority The priority of the flow entry
in_port The OpenFlow port number on which the packets are
received
dl_src The source address
dl_dst The destination address
actions A set of actions applied to a packet. The actions are: “drop”,
“goto_table”, “pop_vlan”, or “push_vlan”
table_id The table ID of the flow entry

Allied Telesis IE340 Series Specifications

General

Brand	Allied Telesis
Model	IE340 Series
Category	Switch
Language	English
