ETHERNET PROTECTION SWITCHED RING (EPSRING™) COMMANDS
SHOW
EPSR
Table 4: Example output from the show epsr command run on a Transit Node
EPSR Information
------------------------------------------------------------
Name ........................ test4
Mode .......................... Transit
Status ........................ Enabled
State ......................... Complete
Control Vlan .................. 4
Data VLAN(s) .................. 20
Interface Mode ................ Ports Only
Primary Port .................. port1.0.3
Status ...................... Forwarding (logically blocking)
Is On Common Segment ........ No
Blocking Control ............ Physical
Secondary Port ................ port1.0.4
Status ...................... Blocked
Is On Common Segment ........ No
Blocking Control ............ Physical
Hello Time .................... 1 s
Failover Time ................. 2 s
Ring Flap Time ................ 0 s
Trap .......................... Enabled
Enhanced Recovery ............. Disabled
SLP Priority .................. 12
------------------------------------------------------------
Table 5: Parameters displayed in the output of the show epsr command
Parameter on
Master Node
Parameter on
Transit Node
Description
Name Name The name of the EPSR instance.
Mode Mode The mode in which the EPSR instance is configured - either Master or
Transit
Status Status Indicates whether the EPSR instance is enabled or disabled
State State Indicates state of the EPSR instance's state machine. Master states
are: Idle, Complete, and Failed. Transit states are Links-Up,
Links-Down, and Pre-Forwarding.
Control Vlan Control Vlan Displays the VID of the EPSR instance's control VLAN.
Data VLAN(s) Data VLAN(s) The VID(s) of the instance's data VLANs.
Interface
Mode
Interface
Mode
Whether the EPSR instance's ring ports are both physical ports (Ports
Only) or are both static aggregators (Channel Groups Only).
Primary Port First Port The EPSR instance's primary ring port.
