Allied Telesis IE340 Series User Manual

C613-50631-01 Rev A Command Reference for IE340 Series 2733
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
G.8032 ETHERNET RING PROTECTION SWITCHING COMMANDS
SHOW
G8032 ERP-INSTANCE STATISTICS
Related
commands
clear g8032 erp-instance statistics
g8032 erp-instance
Command
changes
Version 5.4.7-0.1: command added
Version 5.4.7-1.1: added to x310 series products
Version 5.4.7-2.1: added to x550 series products
Version 5.4.8-0.2: added to SBx8100 series products
Version 5.4.8-1.1: added to SBx908 GEN2 series products
Table 2: Parameters in the output from the show g8032 erp-instance statistics
command
Parameter Description
Instance Name The configured <erp-instance-name> for this instance.
Local clear The number of Clear commands invoked locally.
FOP-TO The number of Failure of Protocol Time Out events seen
locally.
RAPS NR The number of R-APS messages with a No Request (NR)
being received or sent.
RAPS NR-RB The number of R-APS messages with a No Request, RPL
Blocked (NR,RB) being received or sent.
RAPS SF The number of R-APS messages with Signal Fail (SF) being
received or sent.
RAPS FS The number of R-APS messages with Forced Switch (FS)
being received or sent.
RAPS MS The number of R-APS messages with Manual Switch (MS)
being received or sent.
RAPS Event The number of R-APS messages with Event (Flush) being
received or sent.
Drop Guard The number of R-APS messages discarded due to Guard
Timer.
Drop Error The number of R-APS messages discarded due to incorrect
MAC Address (unmatched Ring-ID), incorrect version,
unusable Request/State, or other invalid code point in one
of the message fields.
Local SF The number of Signal Fail events seen locally.
FOP-PM The number of Failure of Protocol events seen locally.
