MEDIA REDUNDANCY PROTOCOL (MRP) COMMANDS
SHOW
COUNTER MRP

Port 2 PDUs Received
MRP_Test ......... 871677
MRP_TopologyChange ......... 0
MRP_LinkUp ......... 0
MRP_LinkDown ......... 0

Port 2 PDUs Transferred
MRP_Test ......... 871677
MRP_TopologyChange ......... 0
MRP_LinkUp ......... 0
MRP_LinkDown ......... 0

Other Counters
State Changes ......... 6
Port Blocked Set ......... 4
Port Forwarding Set ......... 2
Multiple Manager ......... 0
Table 56-1: Parameters in the output from show counter mrp
Parameter Description
MRP Started The number of times the MRP service has been started
with the service mrp command. This counter increases
each time it is stopped and started.
MRP Dispatcher
MRP Timer Tick
Internal timer tick that provides timing for the protocol
and the dispatcher. This is called to process timing events,
packet reception, and state changes.
MRP Packet RX The number of MRP protocol packets received.
MRP Packet RX Error The number of failures when receiving a packet.
MRP Packet TX The number of MRP protocol packets sent.
MRP Packet TX Error The number of failures when sending a packet.
MRP_Test The number of test frames sent and received by the Media
Redundancy Manager (MRM) to test if the ring is open or
closed.
MRP_TopologyChange The number of topology change frames sent from the
MRM to indicate ring topology changes to Media
Redundancy Clients (MRC).
MRP_LinkUp
MRP_LinkDown
The number of Link Up/Down frames sent from MRC to
indicate a link state change on one of its ring ports.
State Changes The number of changes in the protocol state. These are
triggered by test packets detecting the ring opening or
closing, and MRP ring port link changes.
Port Blocked Set The number of times a ring port has been set to blocking.
