AMF AND AMF PLUS COMMANDS
SHOW
ATMF DETAIL
Table 58: Parameter definitions from the show atmf detail command
Parameter Definition
Network MTU The network MTU for the ATMF network.
Network Name The AMF network that a particular node belongs to.
Node Name The name assigned to a particular node.
Node Address An address used to access a remotely located node. This is simply the Node Name
plus the dotted suffix atmf (.atmf).
Node ID A unique identifier assigned to a node on an AMF network.
Node Depth The number of nodes in the path from this node to the level of the AMF root node. It
can be thought of as the vertical depth of the AMF network from a particular node
to the zero level of the AMF root node.
Domain State The state of a node in a Domain in an AMF network as Controller/Backup.
Recovery State The AMF node recovery status. Indicates whether a node recovery is in progress on
this device - Auto, Manual, or None.
Recovery Over
ETH Ports
Allow AMF recovery over the Eth port on an AR-series device.
Log Verbose
Setting
The state of the atmf log-verbose command.
Topology GUI This feature allows your AMF network to interact with Vista Manager EX and must be
enabled on your AMF master.
Management VLAN The VLAN created for traffic between nodes of different domain (up/down links).
• VLAN ID - in this example VLAN 4092 is configured as the Management VLAN.
• Management Subnet - the network prefix for the subnet.
• Management IP Address - the IP address allocated for this traffic.
• Management Mask - the subnet mask used to create a subnet for this traffic
(255.255.128.0).
Domain VLAN The VLAN assigned for traffic between nodes of the same domain (crosslink).
• VLAN ID - in this example VLAN 4091 is configured as the domain VLAN.
• Domain Subnet - the subnet address used for this traffic.
• Domain IP Address - the IP address allocated for this traffic.
• Domain Mask - the subnet mask used to create a subnet for this traffic
(255.255.128.0).
Node Depth The number of nodes in the path from this node to the core domain.
