C613-50631-01 Rev A Command Reference for IE340 Series 2983
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
AMF AND AMF PLUS COMMANDS
SHOW
ATMF LINKS DETAIL
For information on filtering and saving command output, see the “Getting Started
with AlliedWare Plus” Feature Overview and Configuration Guide.
Node Transaction
List
List of transactions from this downlink domain node.
• Node - 0 links are not blocked to the domain. 1 All links are blocked to the
domain.
• Transaction ID - Transaction id for this node.
• Domain List: Shows list of nodes in the current domain and their links to the
downlink domain.:
• Domain - Domain name of the downlink node.
• Node - Name of the node in the current domain.
• Ifindex - Interface index for the link from the node to the downlink domain.
• Transaction ID - Transaction id of the node in the current domain.
• Flags - As mentioned above.
Up/Downlink Ports
Information
Shows all the configured up and down link ports on this node:
• Port - Name of the local port.
•Ifindex - Interface index of the local port.
• VR ID - Virtual router id for the local port.
• Port Status - Shows status of the local port on the Node as UP/DOWN.
• Port State - AMF state of the local port.
• Adjacent Node - nodename of the adjacent node.
• Adjacent Internal ID - Unique node identifier of the remote node.
• Adjacent Ifindex - Interface index for the port of adjacent AMF node.
• Adjacent Board ID - Product identifier for the adjacent node.
• Adjacent VR ID - Virtual router id for the port on adjacent AMF node.
• Adjacent MAC - MAC address for the port on adjacent AMF node.
• Adjacent Domain Controller - nodename of the Domain controller for
Adjacent AMF node.
• Adjacent Domain Controller MAC - MAC address of the Domain controller for
Adjacent AMF node.
• Port Forwarding State - Local port forwarding state Forwarding or Blocking.
• Port BPDU Receive Count - count of AMF protocol PDU's received.
• Port Sequence Number - hello sequence number, incremented every time
the data in the hello packet changes.
• Port Adjacent Sequence Number - remote ends sequence number used to
check if we need to process this packet or just note it arrived.
• Port Last Message Response - response from the remote neighbor to our last
hello packet.
Table 59: Parameter definitions from the show atmf links detail command output (cont.)
Parameter Definition
