C613-50631-01 Rev A Command Reference for IE340 Series 3224
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
LLDP COMMANDS
LLDP
MED-TLV-SELECT
Default By default LLDP-MED Capabilities, Network Policy, Location Identification and
Extended Power-via-MDI TLVs are enabled. Therefore, if LLDP is enabled using the
lldp run command, by default LLDP-MED advertisements are transmitted on ports
that detect LLDP-MED neighbors connected to them.
Mode Interface Configuration
Usage notes LLDP-MED TLVs are only sent in advertisements via a port if there is an
LLDP-MED-capable device connected to it. To see whether there are LLDP-MED
capable devices connected to the ports, use the show lldp neighbors command.
Examples To enable inclusion of the Inventory TLV Set in advertisements transmitted via
port1.0.1 and port1.0.2, use the commands:
awplus# configure terminal
awplus(config)# interface port1.0.1,port1.0.2
awplus(config-if)# lldp med-tlv-select inventory-management
To exclude the Inventory TLV Set in advertisements transmitted via port1.0.1 and
port1.0.2, use the commands:
awplus# configure terminal
awplus(config)# interface port1.0.1,port1.0.2
awplus(config-if)# no lldp med-tlv-select inventory-management
To disable LLDP-MED advertisements transmitted via port1.0.1 and port1.0.2,
disable all these TLVs using the commands:
awplus# configure terminal
awplus(config)# interface port1.0.1,port1.0.2
awplus(config-if)# no lldp med-tlv-select all
inventory-management Inventory Management TLV Set, including the following
TLVs:
• Hardware Revision
• Firmware Revision
• Software Revision
• Serial Number
• Manufacturer Name
•Model Name
• Asset ID
all All LLDP-MED Organizationally Specific TLVs.
Parameter Description
