Allied Telesis IE340 Series User Manual

C613-50631-01 Rev A Command Reference for IE340 Series 3259
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
LLDP COMMANDS
SHOW
LLDP LOCAL-INFO
Power Via MDI (PoE) PoE-capability and current status on the local port.
Port Class Whether the device is a PSE (Power Sourcing Entity) or a
PD (Powered Device).
Pair Control
Ability
Whether power pair selection can be controlled.
Power Pairs Which power pairs are selected for power ("Signal Pairs"
or "Spare Pairs") if pair selection can be controlled.
Power Class The power class of the PD device on the port (class 0, 1, 2,
3 or 4).
Link Aggregation Whether the link is capable of being aggregated and it is
currently in an aggregation.
Aggregated Port-ID Aggregated port identifier.
Maximum Frame Size The maximum frame size capability of the implemented
MAC and PHY.
LLDP-MED Device
Type
LLDP-MED device type.
LLDP-MED
Capabilities
Capabilities LLDP-MED capabilities supported on the
local port.
Network Policy List of network policies configured on the local port.
VLAN ID VLAN identifier for the port for the specified application
type.
Tagged Flag Whether the VLAN ID is to be used as tagged or
untagged.
Layer-2 Priority: Layer 2 User Priority (in the range 0 to 7).
DSCP Value Diffserv codepoint (in the range 0 to 63).
Location
Identification
Location configured on the local port.
Extended Power Via
MDI (PoE)
PoE-capability and current status of the PoE parameters
for Extended Power-Via-MDI TLV on the local port.
Power Source The power source the switch currently uses; either
primary power or backup power.
Power Priority The power priority configured on the port; either critical,
high or low.
Table 63-1: Parameters in the output of show lldp local-info (cont.)
Parameter Description
