C613-50631-01 Rev A Command Reference for IE340 Series 691
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
VLAN COMMANDS
VLAN
CLASSIFIER RULE PROTO
Mode Global Configuration
Usage notes If the protocol type matches the protocol specified in the VLAN classifier rule, the
received packets are mapped to the specified VLAN. Ethernet Frame Numbers may
be entered in place of the protocol names listed. For a full list please refer to the
IANA list online:ď€
www.iana.org/assignments/ieee-802-numbers/ieee-802-numbers.txt
[decsyscomm|24583] DEC Systems Comms
Arch protocol
[g8bpqx25|2303] G8BPQ AX.25 protocol
[ieeeaddrtrans|2561] Xerox IEEE802.3 PUP
Address
[ieeepup|2560] Xerox IEEE802.3 PUP
protocol
[ip|2048] IP protocol
[ipv6|34525] IPv6 protocol
[ipx|33079] IPX protocol
[netbeui|61680] IBM NETBIOS/NETBEUI
protocol
[netbeui|61681] IBM NETBIOS/NETBEUI
protocol
[pppdiscovery|34915] PPPoE discovery protocol
[pppsession|34916] PPPoE session protocol
[rarp|32821] Reverse Address
Resolution protocol
[x25|2056] CCITT.25 protocol
[xeroxaddrtrans|513] Xerox PUP Address
Translation protocol
[xeroxpup|512] Xerox PUP protocol
ethv2 Ethernet Version 2 encapsulation
nosnapllc LLC without SNAP encapsulation
snapllc LLC SNAP encapsulation
<1-4094> Specify a VLAN ID to which an untagged packet is mapped in the
range <1-4094>
Parameter Description
