Allied Telesis IE340 Series User Manual

C613-50631-01 Rev A Command Reference for IE340 Series 700
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
SPANNING TREE COMMANDS
DEBUG
MSTP (RSTP AND STP)
command. The default terminal monitor filter will select and display these
messages. Alternatively, the messages can be directed to any of the other log
outputs by adding a filter for the MSTP application using log buffered (filter)
command:
awplus# configure terminal
awplus(config)# log buffered program mstp
Output 1
Usage 2 Use the debug mstp packet rx|tx decode interface command to generate
debugging messages containing the entire contents of a BPDU displayed in
readable text for transmitted and received xSTP BPDUs. The debugging can be
activated on a per-port basis and transmit and receive debugging is controlled
independently. Although this command uses the keyword mstp, it displays
debugging output for RSTP and STP protocols as well as the MSTP protocol.
Due to the likely volume of output, these debug messages are best viewed using
the terminal monitor command before issuing the relevant debug mstp
command. The default terminal monitor filter will select and display these
messages. Alternatively, the messages can be directed to any of the other log
outputs by adding a filter for the MSTP application using the log buffered (filter)
command:
awplus(config)# log buffered program mstp
Output 2 In MSTP mode - an MSTP BPDU with 1 MSTI:
awplus#terminal monitor
awplus#debug mstp topology-change interface port1.0.4
10:09:09 awplus MSTP[1409]: Topology change rcvd on port1.0.4 (internal)
10:09:09 awplus MSTP[1409]: Topology change rcvd on MSTI 1 port1.0.4
awplus#debug mstp topology-change interface port1.0.6
10:09:29 awplus MSTP[1409]: Topology change rcvd on port1.0.6 (external)
10:09:29 awplus MSTP[1409]: Topology change rcvd on MSTI 1 port1.0.6
