C613-50631-01 Rev A Command Reference for IE340 Series 829
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
POWER OVER ETHERNET COMMANDS
SHOW
POWER-INLINE
Related
commands
show power-inline counters
show power-inline interface
Command
changes
Version 5.4.8-0.2: added to x550 series products
Power The power consumption in milliwatts (mW) for the PoE
port when this command was entered.
Device The description of the connected PD device if a description
has been added with the power-inline description
command. No description is shown for PDs not configured
with the power-inline description command.
Class The class of the connected PD, if power is being supplied to
the PD.
Max (mW) The power in milliwatts (mW) allocated for the PoE port.
Additionally, note the following as displayed per PoE port:
• [U] if the power limit for a port was user configured (with
the power-inline max command).
• [L] if the power limit for a port was supplied by LLDP.
• [C] if the power limit for a port was supplied by the PD
class.
HANP Whether High Availability Network Power is enabled (on) or
not (off) on the port. HANP is also known as Continuous
PoE. Continuous PoE enables the switch to perform actions
such as software upgrades without forcing the Powered
Devices to power cycle. This allows, for example, IP cameras
to buffer data instead of losing it. This column only displays
if Continuous PoE has been enabled globally on the switch.
Table 1: Parameters in the show power-inline command output (cont.)
Parameter Description
