Allied Telesis IE340 Series User Manual

C613-50631-01 Rev A Command Reference for IE340 Series 2728
AlliedWare Plus™ Operating System - Version 5.5.3-0.x
G.8032 ETHERNET RING PROTECTION SWITCHING COMMANDS
SHOW
G8032 ERP-INSTANCE
------------------------------------------------------------------
East Receiving | West Receiving
------------------------------------------------------------------
Hold Off Timer - | Hold Off Timer -
Signal Fail - | Signal Fail -
Failure of Proto-PM false | Failure of Proto-PM false
Version - | Version -
Request - | Request -
RPL-Block - | RPL-Block -
DNF - | DNF -
Block Port Ref - | Block Port Ref -
NodeID - | NodeID -
------------------------------------------------------------------
East Sending | West Sending
------------------------------------------------------------------
Version 1 | Version 1
Request NR | Request NR
RPL-Block RB | RPL-Block RB
DNF 1 | DNF 1
Block Port Ref 1 | Block Port Ref 1
NodeID 0000.cd37.0c25 | NodeID 0000.cd37.0c25
------------------------------------------------------------------
Table 1: Parameters in the output from the show g8032 erp-instance
command.
Parameter Description
Instance name The configured <erp-instance-name> for this instance.
Admin State The configured administrative state of this instance, either
enabled or disabled. When the ERP instance is disabled, all
dynamic data for other parameters in this table will be
shown as "-", except for the East Link or West Link which
will show the last known block or unblocked state.
G.8032 State A dynamic parameter showing the current state of the
instance per the G.8032 state machine. If the ERP Instance
is disabled, it will be in the INIT state.
Phy Ring Shows the Physical Ring Instance name that this ERP
Instance is associated with along with the East/West or
Terminating Interface used by the Physical Ring Instance.
East Link or West
Link
A dynamic variable showing whether the instance's ring
port and its VLANs are blocked or not. In the special case
of an interconnection node where a sub-ring terminates,
both the East Link and the West Link are the same.
RPL Role East Link
or West Link
Shows the configuration of the link's role.
