Siemens SINAMICS S Series - p9542 SI motion act val comparison tol (crosswise) (Control Unit); SI Mtn act val tol; p9544 SI motion actual value comparison tolerance (referencing) (CU); SI Mtn ref tol

Parameters
List of parameters
1-1008
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Sets the tolerance for the cross-check of the actual position between the two monitoring channels.
Dependency: Refer to: C01711
Note: A change only becomes effective after a POWER ON.
Description: Sets the tolerance for the cross-check of the actual position between the two monitoring channels.
Dependency: Refer to: C01711
Note: A change only becomes effective after a POWER ON.
Description: Sets the tolerance to check the actual values after referencing (incremental encoder) or when powering-up (abso-
lute encoder).
Dependency: Refer to: C01711
Note: A change only becomes effective after a POWER ON.
Description: Sets the tolerance to check the actual values after referencing (incremental encoder) or when powering-up (abso-
lute encoder).
Dependency: Refer to: C01711
Note: A change only becomes effective after a POWER ON.
p9542 SI motion act val comparison tol (crosswise) (Control Unit) / SI Mtn act val tol
SERVO, VECTOR Can be changed: C2 Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Safety Integrated Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0.0010 [mm] 360.0000 [mm] 0.1000 [mm]
p9542 SI motion act val comparison tol (crosswise) (Control Unit) / SI Mtn act val tol
SERVO (Safety rot),
VECTOR (Safety rot)
Can be changed: C2 Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Safety Integrated Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0.0010 [°] 360.0000 [°] 0.1000 [°]
p9544 SI motion actual value comparison tolerance (referencing) (CU) / SI Mtn ref tol
SERVO, VECTOR Can be changed: U, T Calculated: - Access level: 4
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Safety Integrated Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0.0000 [mm] 36.0000 [mm] 0.0100 [mm]
p9544 SI motion actual value comparison tolerance (referencing) (CU) / SI Mtn ref tol
SERVO (Safety rot),
VECTOR (Safety rot)
Can be changed: U, T Calculated: - Access level: 4
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Safety Integrated Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0.0000 [°] 36.0000 [°] 0.0100 [°]
