Parameters
List of parameters
1-462
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Activates current setpoint filters 1 to 4.
Dependency: The current setpoint filters are parameterized with p1656 to p1676.
Note: If not all of the filters are required, then the filters should be used consecutively starting from filter 1.
Description: Activates current setpoint filters 1 to 2.
Dependency: The current setpoint filters are parameterized with p1656 to p1666.
Note: If not all of the filters are required, then the filters should be used consecutively starting from filter 1.
Description: Sets the current setpoint filter 1 as low pass (PT2) or as extended general 2nd-order filter.
Values: 1: Low pass: PT2
2: General 2nd-order filter
Dependency: The current setpoint filters are parameterized with p1656 to p1676.
Note: For an extended general 2nd order filter, by inserting the same natural frequency in both the numerator and in the
denominator, i.e. bandstop frequency, a bandstop filter is implemented. If the numerator damping of zero is
selected, the bandstop frequency is completely suppressed. The denominator damping can be determined from the
equation for the 3 dB bandwidth: f_3dB bandwidth = 2 * D_denominator * f_bandstop frequency
p1656[0...n] Activates current setpoint filter / I_set_filt active
SERVO Can be changed: U, T Calculated: CALC_MOD_CON Access level: 3
Data type: Unsigned16 Dynamic index: DDS, p0180 Func. diagram: 5710
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 0001 bin
Bit field: Bit Signal name 1 signal 0 signal FP
00 Filter 1 Active Inactive -
01 Filter 2 Active Inactive -
02 Filter 3 Active Inactive -
03 Filter 4 Active Inactive -
p1656[0...n] Activates current setpoint filter / I_set_filt active
VECTOR (n/M) Can be changed: U, T Calculated: - Access level: 3
Data type: Unsigned16 Dynamic index: DDS, p0180 Func. diagram: 6710
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: REL Expert list: 1
Min Max Factory setting
- - 0001 bin
Bit field: Bit Signal name 1 signal 0 signal FP
00 Filter 1 Active Inactive -
01 Filter 2 Active Inactive -
p1657[0...n] Current setpoint filter 1 type / I_set_filt 1 Typ
SERVO, VECTOR
(n/M)
Can be changed: U, T Calculated: CALC_MOD_CON Access level: 3
Data type: Integer16 Dynamic index: DDS, p0180 Func. diagram: 5710, 6710
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: REL Expert list: 1
Min Max Factory setting
1 2 1
