List of parameters
Parameters
1-511
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Bit 01: p0320, p0360, p0362 ... p0369
Bit 02: p0341, p0342
Bit 03: p1400.0, p1458, p1459, p1460, p1462, p1463, p1470, p1472, p1496
Bit 04: Dependent on p1960
Bit 05: p0391, p0392, p0393, p1402.2 only for induction motors
p1960 = 1, 3: p1400.0, p1458, p1459, p1470, p1472, p1496
p1960 = 2, 4: p1458, p1459, p1460, p1461, p1462, p1463, p1496
The identification of the q leakage inductance can only be carried out for unloaded or motors with only a low load
(load approx. 30% below the rated motor torque). Only then is a current controller adaptation (p0391 ... p0393)
parameterized if the q-leakage inductance under no-load conditions is at least 30 % higher than the total leakage
inductance (p0356, p0358).
Description: Activates the rotating measurement.
Values: -3: Accept identified parameters
-2: Acknowledge encoder inversion actual value (F07993)
-1: Start motor data identification without acceptance
0: Inactive/inhibit
1: Start motor data identification with acceptance
Recommend.: Before carrying out the rotation measurement for motors with brake, the brake should be opened (p1215 = 2) - as
long as this can be done without incurring any danger. The commutation angle and the direction are also deter-
mined.
Dependency: Refer to: r1934, r1935, r1936, r1937, r1938, r1939, r1947, r1948, p1958, p1959, r1962, r1963, r1969
Refer to: F07990, A07991, F07993
Danger: For the rotating measurement, the motor is accelerated up to the maximum speed. Only the parameterized current
limit (p0640) and the maximum speed (p1082) are effective.
The behavior of the motor can be influenced using the direction inhibit (p1959.14, p1959.15) and the ramp-
up/ramp-down time (p1958).
Caution: In order to permanently accept the determined settings they must be saved in a non-volatile fashion (p0971,
p0977).
Note: The rotating measurement can only be selected when the pulses of all of the drive objects of the Control Unit have
been canceled. After selection, all of the other drive objects of the Control Unit are interlocked so that they cannot
be powered-up until the rotating measurement has been completed or de-selected.
When the rotating measurement is activated (p1960 = 1), it is not possible to save the parameters (p0971, p0977).
Description: Activates the rotating measurement.
Values: -3: Accept identified parameters
-2: Acknowledge encoder inversion actual value (F07993)
-1: Start motor data identification without acceptance
0: Inactive/inhibit
1: Start motor data identification with acceptance
p1960 Rotating measurement selection / Rot meas sel
SERVO Can be changed: T Calculated: - Access level: 2
Data type: Integer16 Dynamic index: - Func. diagram: -
P-Group: Motor identification Units group: - Unit selection: -
Not for motor type: REL Expert list: 1
Min Max Factory setting
-3 1 0
p1960 Velocity controller optimization selection / Rot meas sel
SERVO (Lin) Can be changed: T Calculated: - Access level: 2
Data type: Integer16 Dynamic index: - Func. diagram: -
P-Group: Motor identification Units group: - Unit selection: -
Not for motor type: REL Expert list: 1
Min Max Factory setting
-3 1 0
