Parameters
List of parameters
1-904
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Displays the temperature actual value of the KTY84 temperature sensor connected to the Voltage Sensing Module
(VSM) for a parallel circuit configuration.
The maximum value of all VSM is displayed in r3666.
Prerequisite:
A KTY84 sensor is connected and p3665 is set to 2.
Dependency: Refer to: p3665
Description: Displays the current actual value from current transducer (CT) 1 at the 10 V input of the particular Voltage Sensing
Module (VSM) for a parallel circuit configuration.
The average value of all VSM is displayed in r3671.
Dependency: Refer to: p3670
Note: The CT for phase 1 is connected at terminals X520.1 and X520.2 of the VSM.
Description: Displays the current actual value from current transducer (CT) 2 at the 10 V input of the particular Voltage Sensing
Module (VSM) for a parallel circuit configuration.
The average value of all VSM is displayed in r3672.
Dependency: Refer to: p3670
Note: The CT for phase 2 is connected at terminals X520.3 and X520.4 of the VSM.
Description: Displays the actual value of the voltage measured at the 10 V input 1 of the Voltage Sensing Modules (VSM).
The average value of all VSM is displayed in r3673.
Dependency: Refer to: p3670
Note: 10 V input 1: Terminals X520.1 and X520.2
r7306[0...n] CO: Par_circuit VSM temperature KTY / VSM temp KTY
A_INF (Parallel),
S_INF (Parallel)
Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: p0140 Func. diagram: -
P-Group: Closed-loop control Units group: 21_1 Unit selection: p0505
Not for motor type: - Expert list: 1
Min Max Factory setting
- [°C] - [°C] - [°C]
r7310[0...n] CO: Par_circuit VSM 10 V input CT1 actual value / VSM CT 1 I_act
A_INF (Parallel),
S_INF (Parallel)
Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: p0140 Func. diagram: -
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- [A] - [A] - [A]
r7311[0...n] CO: Par_circuit VSM 10 V input CT2 actual value / VSM CT 2 I_act
A_INF (Parallel),
S_INF (Parallel)
Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: p0140 Func. diagram: -
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- [A] - [A] - [A]
r7315[0...n] CO: Par_circuit VSM 10 V input 1 actual value / VSM inp 1 V_act
A_INF (Parallel),
S_INF (Parallel)
Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: p0140 Func. diagram: -
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- [V] - [V] - [V]
