Faults and Alarms
List of faults and alarms
3-1650
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Remedy: - check the tachometer feeder cable for interruptions.
- check the grounding of the tachometer shielding.
- if required, increase the setting of p0492.
Reaction upon F: A_INFEED: NONE (OFF1, OFF2)
SERVO: NONE (IASC / DCBRAKE, OFF1, OFF2, OFF3, STOP1, STOP2)
VECTOR: NONE (IASC / DCBRAKE, OFF1, OFF2, OFF3, STOP1, STOP2)
Acknowl. upon F: IMMEDIATELY
Reaction upon N: NONE
Acknowl. upon N: NONE
A31419 (F, N) Encoder 1: Track A or B outside the tolerance range
Drive object: All objects
Reaction: NONE
Acknowledge: NONE
Cause: The amplitude, phase or offset correction for track A or B is at the limit.
Amplitude error correction: Amplitude B / Amplitude A = 0.78 ... 1.27
Phase: <84 degrees or >96 degrees
SMC20: Offset correction: +/-140 mV
SMC10: Offset correction: +/-650 mV
Alarm value (r2124, interpret hexadecimal):
xxx1: Minimum of the offset correction, track B
xxx2: Maximum of the offset correction, track B
xx1x: Minimum of the offset correction, track A
xx2x: Maximum of the offset correction, track A
x1xx: Minimum of the amplitude correction, track B/A
x2xx: Maximum of the amplitude correction, track B/A
1xxx: Minimum of the phase error correction
2xxx: Maximum of the phase error correction
See also: p0491 (Motor encoder fault response ENCODER)
Remedy: - check mechanical mounting tolerances for encoders without their own bearings (e.g. toothed-wheel encoders).
- check the plug connections (also the transition resistance).
- check the encoder signals.
- replace the encoder or encoder cable.
Reaction upon F: A_INFEED: NONE (OFF1, OFF2)
SERVO: NONE (ENCODER, IASC / DCBRAKE, OFF1, OFF2, OFF3, STOP1, STOP2)
VECTOR: NONE (ENCODER, IASC / DCBRAKE, OFF1, OFF2, OFF3, STOP1, STOP2)
Acknowl. upon F: IMMEDIATELY
Reaction upon N: NONE
Acknowl. upon N: NONE
A31421 (F, N) Encoder 1: Coarse position error
Drive object: All objects
Reaction: NONE
Acknowledge: NONE
Cause: For this encoder, this coarse position is incorrect.
Fault value (r0949, interpret decimal):
3:
The absolute position of the serial protocol and track A/B differ by half an encoder pulse. The absolute position must
have its zero position in the quadrants in which both tracks are negative otherwise the position can be incorrect by
one encoder pulse.
Remedy: Re fault value = 3:
For Sensor Module Cabinet (SMC) and Sensor Module External (SME), the following applies:
- use an encoder cable from Siemens.
- for encoder cables that you have fabricated yourself, interchange track A with A* and B with B*.
For Sensor Module Integrated (SMI), the following applies:
- replace the component.
