List of parameters

Parameters

1-541

SINAMICS S List Manual (LH1), 07/2007

[19] = PZD 20

[20] = PZD 21

[21] = PZD 22

[22] = PZD 23

[23] = PZD 24

[24] = PZD 25

[25] = PZD 26

[26] = PZD 27

[27] = PZD 28

[28] = PZD 29

[29] = PZD 30

[30] = PZD 31

[31] = PZD 32

Dependency: Refer to: p2051, p2061

Note: IF1: Interface 1

Description: Displays the PZD (actual values) with word format sent to the PROFIBUS master.

Index: [0] = PZD 1

[1] = PZD 2

[2] = PZD 3

[3] = PZD 4

[4] = PZD 5

Bit field: Bit Signal name 1 signal 0 signal FP

00 Bit 0 On Off -

01 Bit 1 On Off -

02 Bit 2 On Off -

03 Bit 3 On Off -

04 Bit 4 On Off -

05 Bit 5 On Off -

06 Bit 6 On Off -

07 Bit 7 On Off -

08 Bit 8 On Off -

09 Bit 9 On Off -

10 Bit 10 On Off -

11 Bit 11 On Off -

12 Bit 12 On Off -

13 Bit 13 On Off -

14 Bit 14 On Off -

15 Bit 15 On Off -

r2053[0...4] IF1 PROFIdrive diagnostics PZD send word / IF1 diag send word

TB30, TM15DI_DO,

TM31

Can be changed: - Calculated: - Access level: 3

Data type: Unsigned16 Dynamic index: - Func. diagram: -

P-Group: Communications Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

- - -
