Parameters

List of parameters

1-566

SINAMICS S List Manual (LH1), 07/2007

Description: Binector output for bit-serial interconnection of a PZD word received from the PROFIBUS/PROFINET master.

The PZD is selected via p2099[1].

Dependency: Refer to: p2099

Description: Setting to invert the individual binector outputs of the connector-binector converter.

Using p2098[0], the signals of CI: p2099[0] are influenced.

Using p2098[1], the signals of CI: p2099[1] are influenced.

r2095.0...15 BO: Connector-binector converter binector output / Con/bin outp

A_INF, B_INF,

CU_CX32, CU_S,

SERVO, S_INF,

TB30, TM15DI_DO,

TM31, TM41, VEC-

TOR

Can be changed: - Calculated: - Access level: 3

Data type: Unsigned16 Dynamic index: - Func. diagram: 2460

P-Group: Communications Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

- - -

Bit field: Bit Signal name 1 signal 0 signal FP

00 Bit 0 On Off -

01 Bit 1 On Off -

02 Bit 2 On Off -

03 Bit 3 On Off -

04 Bit 4 On Off -

05 Bit 5 On Off -

06 Bit 6 On Off -

07 Bit 7 On Off -

08 Bit 8 On Off -

09 Bit 9 On Off -

10 Bit 10 On Off -

11 Bit 11 On Off -

12 Bit 12 On Off -

13 Bit 13 On Off -

14 Bit 14 On Off -

15 Bit 15 On Off -

p2098[0...1] Inverter connector-binector converter binector output / Con/bin outp inv

A_INF, B_INF,

CU_CX32, CU_S,

SERVO, S_INF,

TB30, TM15DI_DO,

TM31, TM41, VEC-

TOR

Can be changed: U, T Calculated: - Access level: 3

Data type: Unsigned16 Dynamic index: - Func. diagram: 2460

P-Group: Communications Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

- - 0000 bin

Bit field: Bit Signal name 1 signal 0 signal FP

00 Bit 0 Inverted Not inverted -

01 Bit 1 Inverted Not inverted -

02 Bit 2 Inverted Not inverted -

03 Bit 3 Inverted Not inverted -

04 Bit 4 Inverted Not inverted -

05 Bit 5 Inverted Not inverted -

06 Bit 6 Inverted Not inverted -

07 Bit 7 Inverted Not inverted -

08 Bit 8 Inverted Not inverted -

09 Bit 9 Inverted Not inverted -

10 Bit 10 Inverted Not inverted -

11 Bit 11 Inverted Not inverted -

12 Bit 12 Inverted Not inverted -
