List of parameters
Parameters
1-899
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Displays the currently permissible line-side absolute current when motoring.
The minimum value of all power units multiplied by the number of Motor Modules is displayed in r0067[0].
Description: Displays the maximum output current of the power unit.
The minimum value of all power units multiplied by the number of Motor Modules is displayed in r0067.
Description: Displays the currently permissible line-side absolute regenerative current.
The minimum value of all power units multiplied by the number of Motor Modules is displayed in r0067[1].
Description: Displays actual absolute current.
The summed value of all power units is displayed in r0068.
Description: Displays the measured actual value of phase U as peak value.
The summed value of all power units is displayed in r0069[0].
r7220[0...n] Infeed par_circuit absolute current value motoring permissible / INF I_abs mot perm
A_INF (Parallel),
S_INF (Parallel)
Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: PDS, p0120 Func. diagram: -
P-Group: Displays, signals Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- [Arms] - [Arms] - [Arms]
r7220[0...n] CO: Par_circuit drive output current maximum / Drv I_outp max
VECTOR (Parallel) Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: PDS, p0120 Func. diagram: -
P-Group: Displays, signals Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- [Arms] - [Arms] - [Arms]
r7221[0...n] Infeed par_circuit absolute current regenerating permissible / INF I_absRegenPerm
A_INF (Parallel),
S_INF (Parallel)
Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: PDS, p0120 Func. diagram: -
P-Group: Displays, signals Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- [Arms] - [Arms] - [Arms]
r7222[0...n] CO: Par_circuit absolute current actual value / I_act abs val
A_INF (Parallel),
S_INF (Parallel),
VECTOR (Parallel)
Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: PDS, p0120 Func. diagram: -
P-Group: Displays, signals Units group: 6_2 Unit selection: p0505
Not for motor type: - Expert list: 1
Min Max Factory setting
- [Arms] - [Arms] - [Arms]
r7223[0...n] CO: Par_circuit phase current actual value phase U / I_phase U act val
A_INF (Parallel),
S_INF (Parallel),
VECTOR (Parallel)
Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: PDS, p0120 Func. diagram: -
P-Group: Displays, signals Units group: 6_5 Unit selection: p0505
Not for motor type: - Expert list: 1
Min Max Factory setting
- [A] - [A] - [A]
