Siemens SINAMICS S Series - r1527 Force limit lower;regenerative without offset; F_max low w;o offs; r1527 Torque limit lower without offset; M_max low w;o offs; p1528[0...n] CI: Torque limit upper;motoring scaling; M_max up;mot scal

List of parameters
Parameters
1-433
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Dependency: p1400 bit 4 = 0: Upper / lower
p1400 bit 4 = 1: Motoring / generating
Refer to: p1520, p1521, p1522, p1523, p1528, p1529
Description: Displays the lower force limit of all force limits without offset.
Dependency: p1400 bit 4 = 0: Upper / lower
p1400 bit 4 = 1: Motoring / generating
Refer to: p1520, p1521, p1522, p1523, p1528, p1529
Description: Displays the lower torque limit of all torque limits without offset.
Dependency: Refer to: p1520, p1521, p1522, p1523, p1528, p1529
Description: Sets the signal source for the scaling of the upper or motoring torque limit in p1522.
Dependency: p1400 bit 4 = 0: Upper / lower
p1400 bit 4 = 1: Motoring / generating
Danger: For p1400.4 = 0 (torque limiting, upper/lower) the following applies:
Negative values. that are obtained as a result of the signal source and the scaling can cause the motor to acceler-
ate in an uncontrollable fashion.
Notice: The parameter may be protected as a result of p0922 or p2079 and cannot be changed.
r1527 Force limit lower/regenerative without offset / F_max low w/o offs
SERVO (Lin) Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: 5620, 5630,
6630, 6640
P-Group: Closed-loop control Units group: 8_1 Unit selection: p0505
Not for motor type: REL Expert list: 1
Min Max Factory setting
- [N] - [N] - [N]
r1527 Torque limit lower without offset / M_max low w/o offs
VECTOR (n/M) Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: 5620, 5630,
6630, 6640
P-Group: Closed-loop control Units group: 7_1 Unit selection: p0505
Not for motor type: REL Expert list: 1
Min Max Factory setting
- [Nm] - [Nm] - [Nm]
p1528[0...n] CI: Torque limit upper/motoring scaling / M_max up/mot scal
SERVO Can be changed: T Calculated: - Access level: 3
Data type: Unsigned32 / FloatingPoint32 Dynamic index: CDS, p0170 Func. diagram: 1610, 3617,
5620, 5630
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: REL Expert list: 1
Min Max Factory setting
- - 1524[0]
