Overview of faults and alarms
Faults and Alarms
3-1429
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
3.1.2 Explanation of the List of Faults and Alarms
The data in the following example has been chosen at random. A description can
contain the information listed below. Some of the information is optional.
The list of faults and alarms (See Section 3.2) has the following layout:
Axxxxx Alarm xxxxx
Axxxxx (F, N) Alarm xxxxx (message type can be changed to F or N)
Fxxxxx Fault xxxxx
Fxxxxx (A, N) Fault xxxxx (report type can be changed to F or N)
Nxxxxx No message
Nxxxxx (A) No message (message type can be changed to A)
Cxxxxx Safety message (separate message buffer)
A report comprises a letter followed by the relevant number.
The meaning of the letters is as follows:
• A means "Alarm"
• F means "Fault"
• N means "No Report" or "Internal Report"
• C means "Safety message"
The optional brackets indicate whether the type specified for this report can be
changed and which report types can be adjusted via parameter (p2118, p2119).
Information about reaction and acknowledgement is specified independently for
a report with adjustable report type (e.g. reaction to F, acknowledgement for F).
- - - - - - - - - - - - - - - - - - - - - - - - -
St
ar
t
o
f
examp
l
e - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Axxxxx (F, N) Fault location (optional): Name
Drive object: List of objects.
Reaction: NONE
Acknowledg-
ment:
NONE
Cause: Description of possible causes.
Fault value (r0949, interpret format): or alarm value (r2124, interpret format): (optional)
Information about fault or alarm values (optional).
Remedy: Description of possible remedies.
Reaction to F: A_INFEED: OFF2 (OFF1, NONE)
SERVO: NONE (OFF1, OFF2, OFF3)
VECTOR: NONE (OFF1, OFF2, OFF3)
A
cknowledge-
ment for F:
IMMEDIATELY (POWER ON)
Reaction to N: NONE
A
cknowledge-
ment for N:
NONE
- - - - - - - - - - - - - - - - - - - - - - - - - End of example - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
