Siemens SINAMICS S Series User Manual

List of parameters
Parameters
1-689
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Load moment of inertia measured from the motor identification.
Description: Sets the mass.
Note: (p0341 * p0342) + p1498 influence the velocity/force pre-control in sensorless operation.
Description: Constant kT1 for the torque characteristic set from the motor identification:
kT(iq)=kT1+kT3*iq^2+kT5*iq^4+kT7*iq^6
Dependency: Refer to: p3046, p3047, p3048
Description: Constant kT1 for the torque characteristic set from the motor identification:
kT(iq)=kT1+kT3*iq^2+kT5*iq^4+kT7*iq^6
Dependency: Refer to: p3046, p3047, p3048
Description: Constant kT3 for the torque characteristic set from the motor identification:
kT(iq)=kT1+kT3*iq^2+kT5*iq^4+kT7*iq^6
p3042 Motor identification - load moment of inertia / MotId LoadMomInert
SERVO Can be changed: U, T Calculated: CALC_MOD_ALL Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Motor identification Units group: 25_1 Unit selection: p0100
Not for motor type: - Expert list: 1
Min Max Factory setting
0.00000 [kgm²] 100000.00000 [kgm²] 0.00000 [kgm²]
p3042 Load mass / Load mass
SERVO (Lin) Can be changed: U, T Calculated: CALC_MOD_ALL Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Motor identification Units group: 27_1 Unit selection: p0100
Not for motor type: - Expert list: 1
Min Max Factory setting
0.00000 [kg] 10000.00000 [kg] 0.00000 [kg]
p3045 Motor identification torque characteristic kT1 / MotID kT1
SERVO (Exp M_ctrl) Can be changed: U, T Calculated: CALC_MOD_ALL Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Motor identification Units group: - Unit selection: -
Not for motor type: ASM, REL, FEM Expert list: 1
Min Max Factory setting
-340.28235E36 [Nm/A] 340.28235E36 [Nm/A] 0.00 [Nm/A]
p3045 Motor identification torque characteristic kT1 / MotID kT1
SERVO (Exp M_ctrl,
Lin)
Can be changed: U, T Calculated: CALC_MOD_ALL Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Motor identification Units group: - Unit selection: -
Not for motor type: ASM, REL, FEM Expert list: 1
Min Max Factory setting
-340.28235E36 [N/Arms] 340.28235E36 [N/Arms] 0.00 [N/Arms]
p3046 Motor identification - torque characteristic kT3 / MotId kT3
SERVO (Exp M_ctrl) Can be changed: U, T Calculated: CALC_MOD_ALL Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Motor identification Units group: - Unit selection: -
Not for motor type: ASM, REL, FEM Expert list: 1
Min Max Factory setting
- - -
