Siemens SINAMICS S Series User Manual

Parameters
List of parameters
1-858
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Sets the sensor type of the second temperature sensor for the motor temperature monitoring.
The parameter can only be changed for SME120, SME125, CU310 and CUA32.
Values: 0: No sensor available
10: PTC fault
11: PTC alarm
12: PTC alarm and timer stage
20: KTY84
30: Bimetallic NC contact fault
31: Bimetallic NC contact alarm
32: Bimetallic NC contact alarm and timer stage
Dependency: Refer to: r0458, p0600, p0601
Note: Terminals for KTY84: X200.1, X200.2
PTC thermistor: Tripping resistance = 1650 Ohm
Description: Sets the sensor type of the third temperature sensor for the motor temperature monitoring.
The parameter can only be changed for SME120, SME125.
Values: 0: No sensor available
10: PTC fault
11: PTC alarm
12: PTC alarm and timer stage
20: KTY84
30: Bimetallic NC contact fault
31: Bimetallic NC contact alarm
32: Bimetallic NC contact alarm and timer stage
Dependency: Refer to: r0458, p0600, p0601
Note: Terminals for PTC triplet and bimetallic: X200.3, X200.4
PTC thermistor: Tripping resistance = 1650 Ohm
Description: Sets the sensor type of the fourth temperature sensor for the motor temperature monitoring.
The parameter can only be changed for SME120, SME125.
p4601[0...n] Motor temperature sensor 2 sensor type / MotTemp_sens typ 2
SERVO, VECTOR Can be changed: C2(3), U, T Calculated: - Access level: 2
Data type: Integer16 Dynamic index: EDS, p0140 Func. diagram: 8016
P-Group: Motor Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 32 0
p4602[0...n] Motor temperature sensor 3 sensor type / MotTemp_sens typ 3
SERVO, VECTOR Can be changed: C2(3), U, T Calculated: - Access level: 2
Data type: Integer16 Dynamic index: EDS, p0140 Func. diagram: 8016
P-Group: Motor Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 32 0
p4603[0...n] Motor temperature sensor 4 sensor type / MotTemp_sens typ 4
SERVO, VECTOR Can be changed: C2(3), U, T Calculated: - Access level: 2
Data type: Integer16 Dynamic index: EDS, p0140 Func. diagram: 8016
P-Group: Motor Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 32 0
