Siemens SINAMICS S Series - p4721[0...1] Trace recording time; Trace record_time; p4722[0...1] Trace trigger delay; Trace trig_delay; p4723[0...1] Time slice cycle for trace; Trace cycle; p4724[0...1] Trace average in the time range; Trace average

List of parameters
Parameters
1-865
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Sets the recording time for the trace.
Index: [0] = Trace 0
[1] = Trace 1
Description: Sets the trigger delay for the trace.
Trigger delay < 0:
Pretrigger: Tracing (recording) starts the selected time before the trigger event actually occurs.
Trigger delay > 0:
Post trigger: Tracing does not start until the set time after the trigger event.
Index: [0] = Trace 0
[1] = Trace 1
Description: Sets the time slice cycle in which the trace is called.
Index: [0] = Trace 0
[1] = Trace 1
Index: [0] = Trace 0
[1] = Trace 1
p4721[0...1] Trace recording time / Trace record_time
CU_CX32, CU_S Can be changed: U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Trace and function generator Units group: - Unit selection: -
Not for motor type: - Expert list: 0
Min Max Factory setting
0.000 [ms] 3600000.000 [ms] 1000.000 [ms]
p4722[0...1] Trace trigger delay / Trace trig_delay
CU_CX32, CU_S Can be changed: U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Trace and function generator Units group: - Unit selection: -
Not for motor type: - Expert list: 0
Min Max Factory setting
-3600000.000 [ms] 3600000.000 [ms] 0.000 [ms]
p4723[0...1] Time slice cycle for trace / Trace cycle
CU_CX32, CU_S Can be changed: U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Trace and function generator Units group: - Unit selection: -
Not for motor type: - Expert list: 0
Min Max Factory setting
0.03125 [ms] 4.00000 [ms] 0.12500 [ms]
p4724[0...1] Trace average in the time range / Trace average
CU_CX32, CU_S Can be changed: U, T Calculated: - Access level: 3
Data type: Unsigned8 Dynamic index: - Func. diagram: -
P-Group: Trace and function generator Units group: - Unit selection: -
Not for motor type: - Expert list: 0
Min Max Factory setting
0000 bin 0001 bin 0001 bin
