Siemens SINAMICS S Series - r7901[0...33] Time slice cycle times; Time slices t_cyc; p8500[0...7] BI: Data transfer 0 bitwise; Transfer 0 bit

List of parameters
Parameters
1-923
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Index: [0] = Sum of the following indices
[1] = Faults (r0944)
[2] = Alarms (r2121)
[3] = Safety messages (r9744)
Dependency: Refer to: r7869
Description: Displays the actual cycle times for all existing time slices.
For r7901[x] = 0, the following applies: The time slice is not active.
Description: Sets the signal source for bitwise data transfer.
These signals are transferred to another Control Unit and are located in BO: r8510.0 ... 7 for further interconnection.
Index: [0] = Send signal to BO: r8510.0
[1] = Send signal to BO: r8510.1
[2] = Send signal to BO: r8510.2
[3] = Send signal to BO: r8510.3
[4] = Send signal to BO: r8510.4
[5] = Send signal to BO: r8510.5
[6] = Send signal to BO: r8510.6
[7] = Send signal to BO: r8510.7
Dependency: Refer to: r8510
r7901[0...33] Time slice cycle times / Time slices t_cyc
CU_CX32, CU_S Can be changed: - Calculated: - Access level: 4
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- [µs] - [µs] - [µs]
p8500[0...7] BI: Data transfer 0 bitwise / Transfer 0 bit
CU_CX32, CU_LINK Can be changed: U, T Calculated: - Access level: 2
Data type: Unsigned32 / Binary Dynamic index: - Func. diagram: 2211
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 0
