List of parameters
Parameters
1-255
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Displays the status and control words of the drive coupling.
Dependency: Refer to: p0864
Note: Bit 0 signals that the infeed is ready.
Bit 1 is used to control an external line contactor.
When the operating signal is transferred via BO: r0863.0 this allows several drives to start (run-up) staggered over
time when they are simultaneously powered-up.
To realize this, the following connections/interconnections are required:
Drive 1: Internconnect BI: p0864 with BO: r0863.0 of the infeed
Drive 2: Internconnect BI: p0864 with BO: r0863.0 of drive 1
Drive 3: Internconnect BI: p0864 with BO: r0863.0 of drive 2, etc.
The first drive only transfers the operating signal to the next drive after it has reached its ready condition.
Description: Sets the signal source for the operating signal of the infeed (e.g. BO: r0863.0).
Dependency: Refer to: r0863
Note: The sequence control of a servo/vector drive requires this signal.
The following applies for an infeed without DRIVE-CLiQ:
For these infeeds, the "ready" signal is available via an output terminal. This signal must be connected to a digital
input. The drives supplied from this infeed must use this signal as ready signal (BI: p0864 = digital input).
Description: Displays the operational readiness of the infeeds when using Smart Line Module (SLM) and Basic Line Module
(BLM) together (mixed operation).
r0863.0...2 CO/BO: Drive coupling status word/control word / CoupleZSW/STW
A_INF, B_INF,
SERVO, S_INF,
VECTOR
Can be changed: - Calculated: - Access level: 2
Data type: Unsigned16 Dynamic index: - Func. diagram: 2634, 8734,
8834, 8934
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Closed-loop control operation Yes No 8732,
8932
01 Energize contactor Yes No 2610,
8734,
8934
02 Infeed line supply failure Yes No -
p0864 BI: Infeed operation / INF operation
SERVO, VECTOR Can be changed: T Calculated: - Access level: 2
Data type: Unsigned32 / Binary Dynamic index: - Func. diagram: 1773, 1774,
2610
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 0
r0873 CO/BO: Infeed, total operation / INF total oper
B_INF, S_INF Can be changed: - Calculated: - Access level: 2
Data type: Unsigned16 Dynamic index: - Func. diagram: 8732, 8832
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
