Siemens SINAMICS S Series - p10012[0...5] SI Motor Module Node Identifier Word 1; SI MM Node ID 1; p10013[0...5] SI Motor Module Node Identifier Word 2; SI MM Node ID 2

List of parameters
Parameters
1-1051
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Index: [0] = Drive 1
[1] = Drive 2
[2] = Drive 3
[3] = Drive 4
[4] = Drive 5
[5] = Drive 6
Description: Sets the actual Node Identifier (word 1, bit 0 ... 31) for the Motor Modules.
Index: [0] = Drive 1
[1] = Drive 2
[2] = Drive 3
[3] = Drive 4
[4] = Drive 5
[5] = Drive 6
Dependency: Refer to: p10013, p10014
Note: The Node Identifier (96 bit) is represented in the following 3 parameters.
p10012[0] word 1 (bit 0 ... 31) for Motor Module 1
...
p10012[5] word 1 (bit 0 ... 31) for Motor Module 6
p10013[0] word 2 (bit 32 ... 63) for Motor Module 1
...
p10013[5] word 2 (bit 32 ... 63) for Motor Module 6
p10014[0] word 3 (bit 64 ... 95) for Motor Module 1
...
p10014[5] word 3 (bit 64 ... 95) for Motor Module 6
Description: Sets the actual Node Identifier (word 2, bit 32 ... 63) for the Motor Modules.
Index: [0] = Drive 1
[1] = Drive 2
[2] = Drive 3
[3] = Drive 4
[4] = Drive 5
[5] = Drive 6
Dependency: Refer to: p10012, p10014
Note: The complete Node Identifier (96 bit) is represented in p10012, p10013 and p10014.
p10012[0...5] SI Motor Module Node Identifier Word 1 / SI MM Node ID 1
TM54F_MA,
TM54F_SL
Can be changed: C2 Calculated: - Access level: 4
Data type: Unsigned32 Dynamic index: - Func. diagram: -
P-Group: Safety Integrated Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0000 hex FFFF FFFF hex 0000 hex
p10013[0...5] SI Motor Module Node Identifier Word 2 / SI MM Node ID 2
TM54F_MA,
TM54F_SL
Can be changed: C2 Calculated: - Access level: 4
Data type: Unsigned32 Dynamic index: - Func. diagram: -
P-Group: Safety Integrated Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0000 hex FFFF FFFF hex 0000 hex
