List of parameters

Parameters

1-237

SINAMICS S List Manual (LH1), 07/2007

Dependency: Changes only become effective if p0776 does not equal 99.

Refer to: p0788

Description: Displays the actual value of a signal determined via a physical address.

Index: [0] = T0

[1] = T1

[2] = T2

Dependency: Only effective when p0776 = 97 or p0776 = 96.

Refer to: p0788

Description: Sets the simulation mode for digital inputs.

Dependency: The setpoint for the input signals is specified using p0796.

Refer to: p0796, p9620

Notice: If a digital input is used as signal source for the function "STO" (BI: p9620) then it is not permissible to select the

simulation mode and this is rejected.

To the terminal designation:

The first designation is valid for CU320, the second for CU310.

Note: This parameter is not saved when data is backed-up (p0971, p0977).

DI: Digital input

DI/DO: Bidirectional Digital Input/Output

r0790[0...2] Test sockets physical address signal value / TestSktsPhyAddrVal

CU_CX32, CU_S Can be changed: - Calculated: - Access level: 4

Data type: Unsigned32 Dynamic index: - Func. diagram: -

P-Group: Terminals Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

- - -

p0795 CU digital inputs simulation mode / CU DI simulation

CU_S Can be changed: U, T Calculated: - Access level: 2

Data type: Unsigned32 Dynamic index: - Func. diagram: 1510, 2020,

2030, 2031, 2100, 2120, 2130,

2131, 2132, 2133

P-Group: Commands Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

- - 0000 bin

Bit field: Bit Signal name 1 signal 0 signal FP

00 DI 0 (X122.1/X121.1) Simulation Terminal eval. -

01 DI 1 (X122.2/X121.2) Simulation Terminal eval. -

02 DI 2 (X122.3/x121.3) Simulation Terminal eval. -

03 DI 3 (X122.4/X121.4) Simulation Terminal eval. -

04 DI 4 (X132.1) Simulation Terminal eval. -

05 DI 5 (X132.2) Simulation Terminal eval. -

06 DI 6 (X132.3) Simulation Terminal eval. -

07 DI 7 (X132.4) Simulation Terminal eval. -

08 DI/DO 8 (X122.7/X121.7) Simulation Terminal eval. -

09 DI/DO 9 (X122.8/X121.8) Simulation Terminal eval. -

10 DI/DO 10 (X122.10/X121.10) Simulation Terminal eval. -

11 DI/DO 11 (X122.11/X121.11) Simulation Terminal eval. -

12 DI/DO 12 (X132.7) Simulation Terminal eval. -

13 DI/DO 13 (X132.8) Simulation Terminal eval. -

14 DI/DO 14 (X132.10) Simulation Terminal eval. -

15 DI/DO 15 (X132.11) Simulation Terminal eval. -
