Parameters

List of parameters

1-90

SINAMICS S List Manual (LH1), 07/2007

Description: Displays the activated function module for the particular drive object.

Note: A "function module" is a functional expansion of a drive object that can be activated when commissioning.

Description: Displays the activated function module for the particular drive object.

Note: A "function module" is a functional expansion of a drive object that can be activated when commissioning.

Description: Displays the basis sampling times.

The sampling times are set using p0112 and p0115. The values for the basis sampling times are determined as a

result of these settings.

Index: [0] = Basis sampling time 0

[1] = Basis sampling time 1

[2] = Basis sampling time 2

r0108 Drive object, function module / DO function module

B_INF, S_INF Can be changed: - Calculated: - Access level: 2

Data type: Unsigned32 Dynamic index: - Func. diagram: -

P-Group: Closed-loop control Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

- - -

Bit field: Bit Signal name 1 signal 0 signal FP

15 Parallel cct. config. Activated Not activated -

18 Free function blocks Activated Not activated -

26 Braking Module external Activated Not activated -

28 Cooling system Activated Not activated -

31 PROFINET Activated Not activated -

r0108 Drive object, function module / DO function module

TB30, TM15DI_DO,

TM31, TM41

Can be changed: - Calculated: - Access level: 2

Data type: Unsigned32 Dynamic index: - Func. diagram: -

P-Group: Closed-loop control Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

- - -

Bit field: Bit Signal name 1 signal 0 signal FP

18 Free function blocks Activated Not activated -

31 PROFINET Activated Not activated -

r0110[0...2] Basis sampling times / t_basis

CU_CX32, CU_S Can be changed: - Calculated: - Access level: 3

Data type: Floating Point Dynamic index: - Func. diagram: -

P-Group: Closed-loop control Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

0.00 [µs] 10000.00 [µs] - [µs]
