Siemens SINAMICS S Series - p7820 DRIVE-CLiQ component component number; DLQ comp_no; p7821 DRIVE-CLiQ component parameter number; DLQ para_no; p7822 DRIVE-CLiQ component parameter index; DLQ para_index; r7823 DRIVE-CLiQ component read parameter value; Read DLQ value

Parameters
List of parameters
1-906
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Sets the component number of the DRIVE-CLiQ component whose parameters are to be accessed.
Dependency: Refer to: p7821, p7822, r7823
Description: Sets the parameter number to access a parameter of a DRIVE-CLiQ component.
Dependency: Refer to: p7820, p7822, r7823
Description: Sets the parameter index to access a parameter of a DRIVE-CLiQ component.
Dependency: Refer to: p7820, p7821, r7823
Description: Displays the parameter value read from the DRIVE-CLiQ component.
Dependency: Refer to: p7820, p7821, p7822
Description: Displays the firmware versions of the DRIVE-CLiQ component selected using p7828[1].
Index: [0] = Reference firmware version
[1] = Actual firmware version
p7820 DRIVE-CLiQ component component number / DLQ comp_no
CU_CX32, CU_S Can be changed: U, T Calculated: - Access level: 4
Data type: Unsigned16 Dynamic index: - Func. diagram: -
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 65535 0
p7821 DRIVE-CLiQ component parameter number / DLQ para_no
CU_CX32, CU_S Can be changed: U, T Calculated: - Access level: 4
Data type: Unsigned16 Dynamic index: - Func. diagram: -
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 65535 0
p7822 DRIVE-CLiQ component parameter index / DLQ para_index
CU_CX32, CU_S Can be changed: U, T Calculated: - Access level: 4
Data type: Unsigned16 Dynamic index: - Func. diagram: -
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 65535 0
r7823 DRIVE-CLiQ component read parameter value / Read DLQ value
CU_CX32, CU_S Can be changed: - Calculated: - Access level: 4
Data type: Unsigned32 Dynamic index: - Func. diagram: -
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
r7825[0...1] DRIVE-CLiQ component version / DLQ version
CU_CX32, CU_S Can be changed: - Calculated: - Access level: 3
Data type: Unsigned32 Dynamic index: - Func. diagram: -
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
