Siemens SINAMICS S Series User Manual

List of parameters
Parameters
1-181
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
--> The evaluation is switched-in and the alarm bit is at position 14 with a low level.
p0435 = 1114
--> The evaluation is switched-in and the alarm bit is at position 14 with a high level.
Description: Sets the position and parity of the parity bit in the SSI protocol.
Notice: The bit may only be positioned before (p0446) or after (p0448) the absolute value in the SSI protocol.
Note: Value = dcba
ba: Position of the parity bit in the protocol (0 ... 63).
c: Parity (0: even, 1: uneven).
d: State of the evaluation (0: Off, 1: On).
Example:
p0436 = 1015
--> The evaluation is switched-in and the parity bit is at position 15 with even parity.
p0436 = 1115
--> The evaluation is switched-in and the parity bit is at position 15 with uneven parity.
Description: Copies the actual serial number of the encoder belong to this encoder data set to p0441 ... p0445.
Example:
For p0440[0] = 1, the serial number of the encoder belonging EDS0 is copied to p0441[0] ... p0445[0].
Values: 0: No action
1: Transfer serial number
Dependency: Refer to: p0441, p0442, p0443, p0444, p0445, r0460, r0461, r0462, r0463, r0464, p1990
Note: For encoders with serial number, encoder replacement is monitored in order to request angular commutation cali-
bration (adjustment) for motor encoders and absolute calibration for direct measuring systems with absolute value
data. The serial number, which from then onwards is used for monitoring purposes, can be transferred using p0440.
In the following cases, copying is automatically started in the following cases:
1.) When commissioning 1FT6, 1FK6, 1FK7 motors.
2.) When writing into p0431.
3.) For p1990 = 1.
p0440 is automatically set to 0 when the copying has been completed.
In order to permanently accept the copied values, it is necessary to save in a non-volatile fashion (p0977).
p0436[0...n] Encoder SSI parity bit / Enc SSI parity bit
SERVO, VECTOR Can be changed: C2(4) Calculated: - Access level: 3
Data type: Unsigned16 Dynamic index: EDS, p0140 Func. diagram: -
P-Group: Encoder Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 65535 0
p0440[0...n] Copy encoder serial number / Copy enc ser_no
SERVO, VECTOR Can be changed: C2(4) Calculated: - Access level: 3
Data type: Integer16 Dynamic index: EDS, p0140 Func. diagram: -
P-Group: Encoder Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 1 0
