Parameters
List of parameters
1-162
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: The saturation characteristics (flux as a function of the magnetizing current) is defined using 4 points.
This parameter specifies the x coordinate (magnetizing current) for the 2nd value pair of the characteristic.
Sets the second magnetizing current of the saturation characteristic as a [%] referred to the rated magnetizing cur-
rent (r0331), for separately-excited synchronous motors referred to the no-load excitation current.
Dependency: The following applies for the magnetizing currents:
p0366 < p0367 < p0368 < p0369
Refer to: p0363
Description: The saturation characteristics (flux as a function of the magnetizing current) is defined using 4 points.
This parameter specifies the x coordinate (magnetizing current) for the 3rd value pair of the characteristic.
Sets the third magnetizing current of the saturation characteristic as a [%] referred to the rated magnetizing current
(r0331), for separately-excited synchronous motors referred to the no-load excitation current.
Dependency: The following applies for the magnetizing currents:
p0366 < p0367 < p0368 < p0369
Refer to: p0364
Description: The saturation characteristics (flux as a function of the magnetizing current) is defined using 4 points.
This parameter specifies the x coordinate (magnetizing current) for the 4th value pair of the characteristic.
Sets the fourth magnetizing current of the saturation characteristic as a [%] referred to the rated magnetizing cur-
rent (r0331), for separately-excited synchronous motors referred to the no-load excitation current.
Dependency: The following applies for the magnetizing currents:
p0366 < p0367 < p0368 < p0369
Refer to: p0365
p0367[0...n] Saturation characteristic I_mag 2 / Mot sat. I_mag 2
VECTOR Can be changed: C2(3), U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: MDS, p0130 Func. diagram: -
P-Group: Motor Units group: - Unit selection: -
Not for motor type: PEM Expert list: 1
Min Max Factory setting
5.0 [%] 800.0 [%] 75.0 [%]
p0368[0...n] Saturation characteristic I_mag 3 / Mot sat. I_mag 3
VECTOR Can be changed: C2(3), U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: MDS, p0130 Func. diagram: -
P-Group: Motor Units group: - Unit selection: -
Not for motor type: PEM Expert list: 1
Min Max Factory setting
5.0 [%] 800.0 [%] 150.0 [%]
p0369[0...n] Saturation characteristic I_mag 4 / Mot sat. I_mag 4
VECTOR Can be changed: C2(3), U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: MDS, p0130 Func. diagram: -
P-Group: Motor Units group: - Unit selection: -
Not for motor type: PEM Expert list: 1
Min Max Factory setting
5.0 [%] 800.0 [%] 210.0 [%]
