Note: If the bypass function is selected ((p1260 > 0), then when the power unit restarts after POWER OFF, the state of
the bypass switch is evaluated. This means that after the ramp-up, it is possible to directly change into the standby
mode. This is only possible for p1267 = 0 (bypass using the control signal) and if the control command after the sys-
tem has been motor is still available (p1266). This function has a high priority than the automatic restart function
(p1210).
The bypass function can only be switched-out again (p1260 = 0) if the bypass is not active or the bypass function
has a fault.
Description: Control and feedback signals of the bypass switch.
Dependency: Refer to: p2369
Note: Control bits 0 and 1 should be interconnected to the signal outputs via which the switches in the motor feeder
cables should be controlled. These should be selected/dimensioned for switching under load.
Description: Sets the dead time for non-synchronized bypass.
Note: This parameter is used to define the changeover time of the contactors. It should not be shorter than the de-magne-
tization time of the motor (p0347).
Description: Sets the delay time to switch back to converter operation for a non-synchronized bypass.
r1261.0...9 CO/BO: Bypass control/status word / Bypass STW / ZSW
VECTOR (Tech_ctrl) Can be changed: - Calculated: - Access level: 2
Data type: Unsigned32 Dynamic index: - Func. diagram: -
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Command switch motor - drive Close Open -
01 Command switch motor - line supply Close Open -
02 Synchronization requested Yes No -
03 Staging status Active Not active -
05 Feedback signal switch motor - drive Closed Opened -
06 Feedback signal switch motor - line supply Closed Opened -
07 Bypass command (from p1266) Yes No -
08 Feedback signal synchronization completed
(from p1268)
Yes No -
09 Staging requested (from p2369) Yes No -
p1262[0...n] Bypass dead time / Bypass t_dead
VECTOR (Tech_ctrl) Can be changed: U, T Calculated: CALC_MOD_REG Access level: 2
Data type: Floating Point Dynamic index: DDS, p0180 Func. diagram: -
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0.000 [s] 20.000 [s] 1.000 [s]
p1263 Debypass delay time / Debypass t_del
VECTOR (Tech_ctrl) Can be changed: U, T Calculated: - Access level: 2
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0.000 [s] 300.000 [s] 1.000 [s]
