Siemens SINAMICS S Series - r3671 CO: VSM 10 V input CT 1 actual value; VSM CT 1 I_act; r3671[0...n] CO: VSM 10 V input CT 1 actual value; VSM CT 1 I_act; r3672 CO: VSM 10 V input CT 2 actual value; VSM CT 2 I_act; r3672[0...n] CO: VSM 10 V input CT 2 actual value; VSM CT 2 I_act

List of parameters
Parameters
1-729
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Note: The CT for phase 1 is connected at terminals X520.1 and X520.2 of the VSM.
The CT for phase 2 is connected at terminals X520.3 and X520.4 of the VSM.
Description: Displays the current actual value from current transducer (CT) 1 at the 10 V input of the Voltage Sensing Module
(VSM).
Dependency: Refer to: p3670
Note: The CT for phase 1 is connected at terminals X520.1 and X520.2 of the VSM.
Description: Displays the current actual value from current transducer (CT) 1 at the 10 V input of the Voltage Sensing Module
(VSM).
Dependency: Refer to: p3670
Note: The CT for phase 1 is connected at terminals X520.1 and X520.2 of the VSM.
Description: Displays the current actual value from current transducer (CT) 2 at the 10 V input of the Voltage Sensing Module
(VSM).
Dependency: Refer to: p3670
Note: The CT for phase 2 is connected at terminals X520.3 and X520.4 of the VSM.
Description: Displays the current actual value from current transducer (CT) 2 at the 10 V input of the Voltage Sensing Module
(VSM).
Dependency: Refer to: p3670
Note: The CT for phase 2 is connected at terminals X520.3 and X520.4 of the VSM.
r3671 CO: VSM 10 V input CT 1 actual value / VSM CT 1 I_act
A_INF, S_INF Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: 9880
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- [A] - [A] - [A]
r3671[0...n] CO: VSM 10 V input CT 1 actual value / VSM CT 1 I_act
VECTOR Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: p0150 Func. diagram: 9880
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- [A] - [A] - [A]
r3672 CO: VSM 10 V input CT 2 actual value / VSM CT 2 I_act
A_INF, S_INF Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: 9880
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- [A] - [A] - [A]
r3672[0...n] CO: VSM 10 V input CT 2 actual value / VSM CT 2 I_act
VECTOR Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: p0150 Func. diagram: 9880
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- [A] - [A] - [A]
