List of parameters

Parameters

1-971

SINAMICS S List Manual (LH1), 07/2007

Dependency: Refer to: r8850

Note: IF2: Interface 2

Description: Binector output for bit-serial interconnection of PZD3 received via interface 2.

Dependency: Refer to: r8850

Note: IF2: Interface 2

Description: Binector output for bit-serial interconnection of PZD4 (normally control word 2) received via interface 2.

11 Bit 11 On Off -

12 Bit 12 On Off -

13 Bit 13 On Off -

14 Bit 14 On Off -

15 Bit 15 On Off -

r8892.0...15 BO: IF2 PZD3 receive bit-serial / IF2 PZD3 recv bitw

SERVO, VECTOR Can be changed: - Calculated: - Access level: 3

Data type: Unsigned16 Dynamic index: - Func. diagram: 2485, 9204,

9206

P-Group: Communications Units group: - Unit selection: -

Not for motor type: - Expert list: 1

Min Max Factory setting

- - -

Bit field: Bit Signal name 1 signal 0 signal FP

00 Bit 0 On Off -

01 Bit 1 On Off -

02 Bit 2 On Off -

03 Bit 3 On Off -

04 Bit 4 On Off -

05 Bit 5 On Off -

06 Bit 6 On Off -

07 Bit 7 On Off -

08 Bit 8 On Off -

09 Bit 9 On Off -

10 Bit 10 On Off -
