List of parameters
Parameters
1-145
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Sets the correction factor for the stall force at a 600 V DC link voltage.
Caution: This parameter is automatically preset for motors from the motor list (p0301). When selecting a catalog motor, this
parameter cannot be changed (write protection). Information in p0300 should be carefully observed when removing
write protection.
Note: The parameter is automatically preset for motors from the motor list (p0301).
Description: Sets the optimum load angle for synchronous motors with reluctance torque (e.g. 1FE ... motors).
This parameter has no significance for induction motors.
SERVO: The load angle is measured at 150% rated motor current.
VECTOR: The load angle is measured at the rated motor current.
Dependency: Refer to: r1947
Caution: This parameter is automatically preset for motors from the motor list (p0301). When selecting a catalog motor, this
parameter cannot be changed (write protection). Information in p0300 should be carefully observed when removing
write protection.
Note: For synchronous motors without reluctance torque, a angle of 90 degrees must be set.
The parameter is automatically preset for motors from the motor list (p0301).
Description: Sets the reluctance torque constant for synchronous motors with reluctance torque (e.g. 1FE ... motors).
This parameter has no significance for induction motors.
Dependency: Refer to: r1939
Caution: This parameter is automatically preset for motors from the motor list (p0301). When selecting a catalog motor, this
parameter cannot be changed (write protection). Information in p0300 should be carefully observed when removing
write protection.
Note: For synchronous motors without reluctance torque, the value 0 must be set.
The parameter is automatically preset for motors from the motor list (p0301).
p0326[0...n] Motor stall force correction factor / Mot F_stall_corr
SERVO (Lin) Can be changed: C2(3), U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: MDS, p0130 Func. diagram: -
P-Group: Motor Units group: - Unit selection: -
Not for motor type: REL, FEM Expert list: 1
Min Max Factory setting
5 [%] 300 [%] 60 [%]
p0327[0...n] Optimum motor load angle / Mot phi_load opt
SERVO, VECTOR Can be changed: C2(3), U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: MDS, p0130 Func. diagram: 5722
P-Group: Motor Units group: - Unit selection: -
Not for motor type: ASM, REL, FEM Expert list: 1
Min Max Factory setting
0.0 [°] 135.0 [°] 90.0 [°]
p0328[0...n] Motor reluctance torque constant / Mot kT_reluctance
SERVO, VECTOR Can be changed: C2(3), U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: MDS, p0130 Func. diagram: -
P-Group: Motor Units group: - Unit selection: -
Not for motor type: ASM, REL, FEM Expert list: 1
Min Max Factory setting
-1000.00 [mH] 1000.00 [mH] 0.00 [mH]
