Parameters
List of parameters
1-202
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Setting parameter of the actual system of units.
Values: 1: System of units SI
2: System of units, referred/SI
3: US system of units
4: System of units, referred/US
Dependency: The parameter cannot be changed if the master control was fetched.
Caution: If a per unit representation is selected and if reference parameters (e.g. p2000) are subsequently changed, then the
physical significance of some closed-loop control parameters will also be adapted where as a result, the closed-
loop control behavior can change (refer to p1576, p1621, p1744, p1752, p1755 and p1609, p1612, p1619, p1620).
Note: Reference parameter for the unit system % are, for example, p2000 ... p2004. Depending on what has been
selected, these are displayed using either SI or US units.
Description: For controller gains, sets the units system between physical/% (dependent on p505) and referred (without dimen-
sions) representation types.
For a physical/% representation, the dependent parameters can be changed-over between
the physical and % representation type using p505.
Values: 0: Physical/% representation (p505)
1: No dimensions (referred) representation type
Note: For SERVO (r0107) the following applies:
The parameter is pre-assigned a value of 0. The parameter cannot be changed.
Description: For controller gains, sets the units system between physical/% (dependent on p505) and referred (without dimen-
sions) representation types.
For a physical/% representation, the dependent parameters can be changed-over between
the physical and % representation type using p505.
Values: 0: Physical/% representation (p505)
1: No dimensions (referred) representation type
Note: For VECTOR (r0107) the following applies:
The parameter is pre-assigned a value of 1. The parameter cannot be changed.
p0505 Selecting the system of units / Select unit sys
A_INF, B_INF,
SERVO, S_INF,
TM41, VECTOR
Can be changed: C2(5) Calculated: - Access level: 1
Data type: Integer16 Dynamic index: - Func. diagram: -
P-Group: Applications Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
1 4 1
p0528 Units system for controller gains / Units for Kp
SERVO, TM41 Can be changed: C2(5) Calculated: - Access level: 4
Data type: Integer16 Dynamic index: - Func. diagram: -
P-Group: Applications Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 1 0
p0528 Units system for controller gains / Units for Kp
VECTOR Can be changed: C2(5) Calculated: - Access level: 4
Data type: Integer16 Dynamic index: - Func. diagram: -
P-Group: Applications Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 1 1
