Siemens SINAMICS S Series User Manual

List of parameters
Parameters
1-257
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Sets the signal source to select the "parking axis" function.
Dependency: BI: p0897 = 0 signal
The function "parking axis" is not selected.
BI: p0897 = 1 signal
The function "parking axis" is selected.
Refer to: r0896
Notice: The parameter may be protected as a result of p0922 or p2079 and cannot be changed.
Note: After it has been selected the "parking axis" function only becomes active when the pulses are canceled.
Description: Displays the control word of drive object 1 (Control Unit).
Description: Displays control word 1 of the infeed.
Note: OC: Operating condition
p0897 BI: Parking axis selection / Parking axis sel
SERVO, VECTOR Can be changed: T Calculated: - Access level: 2
Data type: Unsigned32 / Binary Dynamic index: - Func. diagram: -
P-Group: Displays, signals Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 0
r0898.0...15 CO/BO: Control word drive object 1 / STW DO1
CU_CX32, CU_S Can be changed: - Calculated: - Access level: 2
Data type: Unsigned16 Dynamic index: - Func. diagram: -
P-Group: Displays, signals Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Synchronization signal SYN Yes No -
01 Real time synchronization PING Yes No -
07 Acknowledge fault Yes No -
12 Master sign-of-life bit 0 Yes No -
13 Master sign-of-life bit 1 Yes No -
14 Master sign-of-life bit 2 Yes No -
15 Master sign-of-life bit 3 Yes No -
r0898.0...10 CO/BO: Control word sequence control infeed / STW seq_ctrl INF
A_INF, S_INF Can be changed: - Calculated: - Access level: 2
Data type: Unsigned16 Dynamic index: - Func. diagram: 1530, 8820,
8920
P-Group: Displays, signals Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 ON/OFF1 Yes No -
01 OC / OFF2 Yes No -
03 Enable operation Yes No -
05 Inhibit motoring operation Yes No -
06 Inhibit regenerating Yes No -
10 Master ctrl by PLC Yes No -
