Parameters
List of parameters
1-390
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Sets the denominator damping for the speed setpoint filter 1 (PT2) of the incremental encoder emulation.
Dependency: Refer to: p1414
Note: This parameter is only effective if the speed setpoint filter in p1414 is activated.
Description: Sets the numerator natural frequency for speed setpoint filter 1 (general filter).
Dependency: Refer to: p1414, p1415
Note: This parameter is only effective if the speed filter is set as a general filter.
The filter is only effective if the natural frequency is less than half of the sampling frequency.
Description: Sets the numerator natural frequency for velocity setpoint filter 1 (general filter).
Dependency: Refer to: p1414, p1415
Note: This parameter is only effective if the velocity filter is set as a general filter.
The filter is only effective if the natural frequency is less than half of the sampling frequency.
Description: Sets the numerator damping for speed setpoint filter 1 (general filter).
Dependency: Refer to: p1414, p1415
Note: This parameter is only effective if the speed filter is set as a general filter.
p1418[0...n] Speed setpoint filter 1 denominator damping / n_set_filt 1 D_d
TM41 Can be changed: U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: DDS, p0180 Func. diagram: 9674
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: REL Expert list: 1
Min Max Factory setting
0.001 1.000 0.700
p1419[0...n] Speed setpoint filter 1 numerator natural frequency / n_set_filt 1 fn_n
SERVO Can be changed: U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: DDS, p0180 Func. diagram: 5020
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: REL Expert list: 1
Min Max Factory setting
0.5 [Hz] 16000.0 [Hz] 2000.0 [Hz]
p1419[0...n] Velocity setpoint filter 1 numerator natural frequency / v_set_filt 1 fn_n
SERVO (Lin) Can be changed: U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: DDS, p0180 Func. diagram: 5020
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: REL Expert list: 1
Min Max Factory setting
0.5 [Hz] 16000.0 [Hz] 2000.0 [Hz]
p1420[0...n] Speed setpoint filter 1 numerator damping / n_set_filt 1 D_n
SERVO Can be changed: U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: DDS, p0180 Func. diagram: 5020
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: REL Expert list: 1
Min Max Factory setting
0.000 10.000 0.700
