Parameters
List of parameters
1-712
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Sets a steady-state supplementary setpoint for the active line supply current.
Dependency: Refer to: p3515
Description: Sets the signal source for the supplementary setpoint of the active current.
Dependency: Refer to: p3514
Note: For a master-slave infeed, the master can enter the current setpoint via this connector input.
Description: Sets the factor to be multiplied by the active current setpoint for the current controller.
For a master slave infeed configuration, the value reduced in this way can be distributed to the slave axes. The
overall gain from the perspective of the voltage controller remains the same.
Description: Displays the unlimited setpoint of the active current controller.
For a master-slave infeed configuration, the master retrieves this setpoint and distributes it to all of the slaves. The
slaves operate in the current-controlled mode.
p3514 Infeed supplementary active current steady-state / INF I_sup_eff stat
A_INF Can be changed: U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: 8940
P-Group: Closed-loop control Units group: 6_2 Unit selection: p0505
Not for motor type: - Expert list: 1
Min Max Factory setting
-1000.00 [Arms] 1000.00 [Arms] 0.00 [Arms]
p3515 CI: Infeed supplementary active current / INF I_suppl eff
A_INF Can be changed: T Calculated: - Access level: 3
Data type: Unsigned32 / FloatingPoint32 Dynamic index: - Func. diagram: 8940
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 0
p3516 Infeed current distribution factor (parallel connection) / INF I_distr_factor
A_INF Can be changed: U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: 8940, 8942
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0.00 [%] 100.00 [%] 100.00 [%]
r3517 CO: Infeed active current controller unlimited setpoint / INF I_act ctrl set
A_INF Can be changed: - Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: 8940
P-Group: Closed-loop control Units group: 6_2 Unit selection: p0505
Not for motor type: - Expert list: 1
Min Max Factory setting
- [Arms] - [Arms] - [Arms]
