C01710 SI Motion CU: STOP E initiated
Drive object: SERVO, VECTOR
Reaction: NONE
Acknowledge: IMMEDIATELY (POWER ON)
Cause: The drive is stopped via a STOP E (retraction motion).
"Safe Operating Stop" (SOS) is activated after the parameterized timer stage has expired.
Possible causes:
- stop request from the higher-level control.
- subsequent response to the message C01714 "SI Motion: Safely reduced speed exceeded".
- subsequent response to the message C01715 "SI Motion: Safe end stop exceeded".
See also: p9554 (SI motion transition time STOP E to SOS (SBH) (Control Unit))
Remedy: - remove the cause of the fault at the control.
- carry out a diagnostics routine for message C01714.
This message can be acknowledged as follows:
- motion monitoring functions integrated in the drive: Via Terminal Module 54F (TM54F) or PROFIsafe
- motion monitoring functions with SINUMERIK: Via the machine control panel
Note:
SI: Safety Integrated
SOS: Safe Operating Stop / SBH: Safe operating stop
C01711 SI Motion CU: Defect in a monitoring channel"
Drive object: SERVO, VECTOR
Reaction: NONE
Acknowledge: IMMEDIATELY (POWER ON)
Cause: When cross-checking and comparing the two monitoring channels, the drive detected a difference between the input
data or results of the monitoring functions and initiated a STOP F. One of the monitoring functions no longer reliably
functions - i.e. safe operation is no longer possible.
If at least one monitoring function is active, then after the parameterized timer stage has expired, the message
C01701 "SI Motion: STOP B initiated" is output.
The message value that resulted in a STOP F is displayed in r9725. The described message values involve the data
cross-check between the Control Unit and Motor Module. If the drive is operated together with a SINUMERIK, the
message values are described in message 27001 of SINUMERIK.
Message value (r9749, interpret decimal):
0 to 999: Number of the cross-checked data that resulted in this fault.
0: Stop request from the other monitoring channel.
1: Status image of monitoring functions SOS, SLS or SLP (result list 1) (r9710[0], r9710[1]).
2: Status image of monitoring function SCA or n < nx (result list 2) (r9711[0], r9711[1]).
3: Pos. act. val. (r9712).
4: Error when synchronizing the crosswise data comparison between the two channels.
5: Function enable signals (p9501, p9301).
6: Limit value for SLS1 (p9531[0], p9331[0]).
7: Limit value for SLS2 (p9531[1], p9331[1]).
8: Limit value for SLS3 (p9531[2], p9331[2]).
9: Limit value for SLS4 (p9531[3], p9331[3]).
10: Standstill tol. (p9530, p9330).
31: Pos. tol. (p9542, p9342).
33: Time, velocity changeover (p9551, p9351).
35: Delay time, pulse canc. (p9556, p9356).
36: Checking time, pulse canc. (p9557, p9357).
37: Trans. time, STOP C to SOS (p9552, p9352).
38: Trans. time STOP D to SOS (p9553, p9353).
40: Stop response for SLS.
42: Shutdown speed, pulse canc. (p9560, p9360).
43: Memory test, stop response (STOP A).
44: Position actual value + limit value SLS1 / safety monitoring clock cycle.
45: Pos. act. val. - limit value SLS1 / safety monitoring clock cycle.
46: Pos. act. val. + limit value SLS2 / safety monitoring clock cycle.
47: Pos. act. val. - limit value SLS2 / safety monitoring clock cycle.
48: Pos. act. val. + limit value SLS3 / safety monitoring clock cycle.
49: Pos. act. val. - limit value SLS3 / safety monitoring clock cycle.
50: Pos. act. val. + limit value SLS4 / safety monitoring clock cycle.
