Siemens SINAMICS S Series - r2055[0...2] PROFIBUS diagnostics standard; PB diag standard; r2056[0...19] PROFIBUS diagnostics expert; PB diag experts; r2057 PROFIBUS address switch diagnostics; PB addr diagn; r2058[0...139] COMM INT receive configuration data; C INT E_config_dat

List of parameters
Parameters
1-543
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Diagnostics display for the PROFIBUS interface.
Index: [0] = Master bus address
[1] = Master input total length bytes
[2] = Master output total length bytes
Description: Displays the setting of the PROFIBUS address switch "DP ADDRESS" on the Control Unit.
Dependency: Refer to: p0918
Description: Displays the configuration data received via COMM BOARD.
Description: Displays the identification data of the COMM BOARD.
Note: Index 0: CB data structure version (e.g.: 100 = V1.00).
Index 1: CB driver version (e.g.: 100 = V1.00).
Index 2: Company, (e.g.: 42 = Siemens).
r2055[0...2] PROFIBUS diagnostics standard / PB diag standard
CU_S Can be changed: - Calculated: - Access level: 3
Data type: Unsigned16 Dynamic index: - Func. diagram: 2410
P-Group: Communications Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
r2056[0...19] PROFIBUS diagnostics expert / PB diag experts
CU_S Can be changed: - Calculated: - Access level: 4
Data type: Unsigned16 Dynamic index: - Func. diagram: -
P-Group: Communications Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
r2057 PROFIBUS address switch diagnostics / PB addr diagn
CU_S Can be changed: - Calculated: - Access level: 3
Data type: Unsigned16 Dynamic index: - Func. diagram: 2410
P-Group: Communications Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
r2058[0...139] COMM INT receive configuration data / C INT E_config_dat
CU_CX32, CU_LINK Can be changed: - Calculated: - Access level: 3
Data type: Unsigned16 Dynamic index: - Func. diagram: -
P-Group: Communications Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
r2059[0...7] COMM INT identification data / C INT ident_dat
CU_CX32, CU_LINK Can be changed: - Calculated: - Access level: 3
Data type: Unsigned16 Dynamic index: - Func. diagram: -
P-Group: Communications Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
