List of parameters
Parameters
1-957
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
The value is displayed as per mille (1/1000) as standard.
Note: Corresponds to the CANopen object 6071 hex + 800 hex * x (x: Drive number 0 ... 7).
The displayed value is calculated as follows:
r8797 [per mille] = M_set [Nm] / p0333 [Nm] * 1000
Description: The factor converts the required velocity units into the internal velocity units (V/s).
With the factor setting, for CANopen, the velocity units are increments/second.
The parameter corresponds to the CANopen object 6094 hex.
The internal velocity is calculated as follows:
n_set_internal = object 6094.1 / object 6094.2 * 1/(p0408 * 2^p0418) * n_set_bus
Index: [0] = Counter
[1] = Denominator
Description: Assignment of the hardware for cyclic communications via PZD interface 1 and interface 2.
Values: 0: Inactive
1: ONBOARD hardware
2: COMM BOARD
99: Automatic
Index: [0] = IF1
[1] = IF2
Note: For value = 99 (automatic) the following applies:
- if neither a COMM BOARD nor CAN is inserted, then PROFIBUS communicates via IF1.
- if a CBE20 is inserted, then PROFINET communicates via IF1.
- CAN always communicates via IF2.
For a value not equal to 99 (automatic) the following applies:
- both indices must be set to a number not equal to 99 (automatic).
A new setting only becomes effective after POWER ON, reset or download.
p8798[0...1] CBC speed conversion factor / n_conv_factor
SERVO (CAN), VEC-
TOR (CAN)
Can be changed: T Calculated: - Access level: 3
Data type: Unsigned32 Dynamic index: - Func. diagram: -
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
1 4294967295 1
p8839[0...1] PZD interface hardware assignment / PZD IF HW assign
CU_S Can be changed: - Calculated: - Access level: 3
Data type: Integer16 Dynamic index: - Func. diagram: -
P-Group: Communications Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 99 99
