Parameters
List of parameters
1-534
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Sets the additional monitoring time to monitor the process data received via PROFIBUS.
If no process data is received within this time, an appropriate message is output.
Dependency: Refer to: F01910
Description: Sets the sampling time for the cyclic interface 1 (IF1).
Note: For clock cycle synchronous operation, the specified bus cycle time applies (Tdp).
Description: Connector output to interconnect PZD (setpoints) with word format received from the PROFIBUS master.
Index: [0] = PZD 1
[1] = PZD 2
[2] = PZD 3
[3] = PZD 4
[4] = PZD 5
Note: IF1: Interface 1
Description: Connector output to interconnect PZD (setpoints) with word format received from the PROFIBUS master.
Index: [0] = PZD 1
[1] = PZD 2
[2] = PZD 3
[3] = PZD 4
[4] = PZD 5
[5] = PZD 6
[6] = PZD 7
[7] = PZD 8
p2047 PROFIBUS additional monitoring time / PB suppl t_monit
CU_S Can be changed: U, T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: 2410
P-Group: Communications Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 [ms] 2000 [ms] 0 [ms]
p2048 IF1 PROFIdrive PZD sampling time / IF1 PZD t_sample
CU_CX32, CU_S Can be changed: C1(3) Calculated: - Access level: 3
Data type: Floating Point Dynamic index: - Func. diagram: -
P-Group: Communications Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
1.00 [ms] 16.00 [ms] 4.00 [ms]
r2050[0...4] CO: IF1 PROFIdrive PZD receive word / IF1 PZD recv word
A_INF, B_INF,
CU_CX32, CU_S,
S_INF, TB30,
TM15DI_DO, TM31
Can be changed: - Calculated: - Access level: 3
Data type: Integer16 Dynamic index: - Func. diagram: -
P-Group: Communications Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
r2050[0...15] CO: IF1 PROFIdrive PZD receive word / IF1 PZD recv word
SERVO, TM41 Can be changed: - Calculated: - Access level: 3
Data type: Integer16 Dynamic index: - Func. diagram: 2440, 2460
P-Group: Communications Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
