List of parameters
Parameters
1-855
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Displays the time when detecting the 1st and 2nd edge for digital input 22 of terminal module 15 (TM15).
The two times are specified as 8 bit values with a resolution of 64 µs.
Note: DI: Digital input
Description: Displays the time when detecting the 1st and 2nd edge for digital input 23 of terminal module 15 (TM15).
The two times are specified as 8 bit values with a resolution of 64 µs.
Note: DI: Digital input
Description: Sets the operating mode for the incremental encoder emulation.
0 -> Encoder emulation using the speed setpoint (p1155)
1 -> Encoder emulation using the encoder position actual value (p4420)
Values: 0: SIMOTION
1: SINAMICS
Note: A change only becomes effective after the next boot.
Description: Sets the mode for the incremental encoder emulation.
r4372 TM15 edge times digital input 22 / TM15 edge_t DI 22
TM15 Can be changed: - Calculated: - Access level: 3
Data type: Unsigned16 Dynamic index: - Func. diagram: -
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
r4373 TM15 edge times digital input 23 / TM15 edge_t DI 23
TM15 Can be changed: - Calculated: - Access level: 3
Data type: Unsigned16 Dynamic index: - Func. diagram: -
P-Group: Commands Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
p4400 TM41 incremental encoder emulation operating mode / Enc_emulat mode
TM41 Can be changed: U, T Calculated: - Access level: 3
Data type: Integer16 Dynamic index: - Func. diagram: 9674, 9676
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 1 0
p4401 TM41 incremental encoder emulation mode / Enc_emulat mode
TM41 Can be changed: U, T Calculated: - Access level: 3
Data type: Unsigned16 Dynamic index: - Func. diagram: 9674, 9676
P-Group: Closed-loop control Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - 0001 bin
Bit field: Bit Signal name 1 signal 0 signal FP
00 Enable zero mark Yes No 9674
