Function Diagrams
Data sets
2-1344
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Figure 2-219 8575 – Motor Data Sets (MDS)
- 8575 -
Function diagram
87654321
fp_8575_51_eng.vsd
DO: SERVO, VECTOR, VECTORGL, VECTORMV
SINAMICS
01.06.06 V02.05.00
Data sets - Motor Data Sets (MDS)
4000.00 µs
Motor selection
r0830.0
r0830
r0830.1
r0830.2
r0830.3
r0830.15
DO
DO
Feedback signal, contactor 0
p0831[0]
Feedback signal, contactor 1
p0831[1]
Feedback signal, contactor 2
p0831[2]
DI
DI
Feedback signal, contactor 3
p0831[3]
DI
Feedback signal, contactor 15
p0831[15]
DI
r0832.0
r0832
Mot_chng fdbk ZSW
r0832.1
r0832.2
r0832.3
r0832.15
Motor
Module
K2
K1
~
M1
3
K1
K1H
K2
~
M2
3
K2
K2H
K1
K1H K2H
0 V
Mot_chng fdbk sig
p0828[C]
p0833.0 (0)
0
1
0
1
Application
Pulse cancellation
MDS15
MDS1
MDS0
p0826[0] Motor number
p0827[0] Bit number
MDS selected
r0838[0]
MDS effective
r0049[0]
p0833.1 (0)
Drive
Application
Drive
Request
pulse enable
Application
Motor changeover
<1> The following applies for the changeover of motor data sets:
For SERVO and VECTOR: The thermal motor model of motors with the same motor number is identical.
For VECTORGL and VECTORMW: The thermal monitoring of motors with the same motor number is identical.
An unequal bit number means that the motor must be changed over.
<1>
DI
1
0
Copy MDS, source
p0139[0] (0)
Copy MDS, target
p0139[1] (0)
Copy MDS, start
p0139[2] (0)
DDS (Drive Data Set)
p0186[0...n] (MDS number)
p0187[0...n] (enc 1 EDS number)
p0188[0...n] (enc 2 EDS number)
p0189[0...n] (enc 3 EDS number)
MDS_chngov ZSW
r0835.0
r0835
(0)
p0820[C]
(0)
p0824[C]
MDS count
p0130 (1)
