Siemens SINAMICS S Series User Manual

Parameters
List of parameters
1-802
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Sets the offset for the analog inputs of terminal module 31 (TM31).
The offset is added to the input signal before the normalization characteristic.
Index: [0] = AI 0 (X521.1/X521.2, S5.0)
[1] = AI 1 (X521.3/X521.4, S5.1)
Description: Sets the offset for the analog input of terminal module 41 (TM41).
The offset is added to the input signal before the normalization characteristic.
Index: [0] = AI 0 (X523.1/X523.2)
Description: Activates the absolute value generation for the analog input signals of the Terminal Board 30 (TB30).
Values: 0: No absolute value generation
1: Absolute value generation switched-in
Index: [0] = AI 0 (X482.1/X482.2)
[1] = AI 1 (X482.3/X482.4)
Description: Activates the absolute value generation for the analog input signals of terminal module 31 (TM31).
Values: 0: No absolute value generation
1: Absolute value generation switched-in
Index: [0] = AI 0 (X521.1/X521.2, S5.0)
[1] = AI 1 (X521.3/X521.4, S5.1)
p4063[0...1] TM31 analog inputs offset / TM31 AI offset
TM31 Can be changed: U, T Calculated: - Access level: 2
Data type: Floating Point Dynamic index: - Func. diagram: 9566, 9568
P-Group: Terminals Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
-20.000 20.000 0.000
p4063[0...0] TM41 analog input, offset / TM41 AI offset
TM41 Can be changed: U, T Calculated: - Access level: 2
Data type: Floating Point Dynamic index: - Func. diagram: 9663
P-Group: Terminals Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
-20.000 [V] 20.000 [V] 0.000 [V]
p4066[0...1] TB30 analog inputs, activate absolute value generation / TB30 AI absVal act
TB30 Can be changed: U, T Calculated: - Access level: 3
Data type: Integer16 Dynamic index: - Func. diagram: 9104
P-Group: Terminals Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 1 0
p4066[0...1] TM31 analog inputs, activate absolute value generation / TM31 AI absVal act
TM31 Can be changed: U, T Calculated: - Access level: 3
Data type: Integer16 Dynamic index: - Func. diagram: 9566, 9568
P-Group: Terminals Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
0 1 0
