Parameters
List of parameters
1-522
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Note: If fault F07414 is present, the following applies:
First set p1990 to 1, then acknowledge the fault and then issue the enable signals.
Description: This function is only required for synchronous motors and can be started when commissioning for the first time or
after replacing an encoder. The function acts on the active motor data set.
Alarm A07971 is output while the angular commutation offset is being determined. p1990 is automatically set to 0
after the angular commutation offset has been determined.
For p1990 = 1 (encoder adjustment with transfer), the following applies:
The angular commutation offset is determined and transferred into p0431.
For p1990 = 2 (encoder adjustment for checking), the following applies:
The angular commutation offset is determined and is not transferred into p0431. For a deviation of more than 6 °
electrical, fault F07413 is output.
Values: 0: Deactivated
1: Activated with transfer
2: Activated for checking
Dependency: In the simulation mode, the parameter cannot be written into.
When selecting the encoder adjustment, the changeover of the drive data sets is suppressed.
Refer to: p0325, p0329, p0431, p1272, p1900
Caution: When the encoder is being adjusted, the motor must be operated without a load - and if a motor holding brake is
being used, this must be opened.
Description: Sets the angle that is added to the commutating angle.
Caution: If the angular correction is not correctly set, when changing over and with closed-loop torque control, the motor can
accelerate to high speeds in spite of the fact that a setpoint of zero has been entered.
Description: Displays diagnostics information for the pole position identification routine.
p1990 Encoder adjustment, determine angular commutation offset / Enc_adj det ang
VECTOR Can be changed: T Calculated: - Access level: 2
Data type: Integer16 Dynamic index: - Func. diagram: -
P-Group: Motor identification Units group: - Unit selection: -
Not for motor type: ASM Expert list: 1
Min Max Factory setting
0 2 0
p1991[0...n] Motor changeover, angular commutation correction / Ang_com corr
SERVO, VECTOR Can be changed: T Calculated: - Access level: 3
Data type: Floating Point Dynamic index: MDS, p0130 Func. diagram: -
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
-180 [°] 180 [°] 0 [°]
r1992 Pole position identification diagnostics / PolID diag
SERVO Can be changed: - Calculated: - Access level: 3
Data type: Unsigned16 Dynamic index: - Func. diagram: -
P-Group: - Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
