Siemens SINAMICS S Series User Manual

Parameters
List of parameters
1-766
© Siemens AG 2007 All Rights Reserved
SINAMICS S List Manual (LH1), 07/2007
Description: Displays the commissioning steps that have been carried out.
Note: When motor rating plate parameters are changed, the final display is reset. When setting the individual bits, all of
the most significant bits are reset.
Bit 00 = Automatic parameterization (p0340 = 1, p3900 > 0).
Bit 02 = Motor data identification (p1910 = 1) successfully completed.
Bit 03 = Rotating measurement (p1960 = 1, 2) successfully completed.
Bit 04 = Motor encoder adjustment (p1990 = 1 of 1960 = 1) successfully completed.
Bit 15 = Equivalent circuit diagram parameters of the motor were subsequently manually changed.
Description: Displays the commissioning steps that have been carried out.
r3925[0...n] Identification final display / Ident final_disp
SERVO Can be changed: - Calculated: - Access level: 3
Data type: Unsigned32 Dynamic index: DDS, p0180 Func. diagram: -
P-Group: Motor Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Complete calculation of motor/control
parameters carried out
Yes No -
02 Motor data identification carried out at
standstill (p1910 = 1)
Yes No -
03 Rotating measurement carried out (p1960 =
1 or 2)
Yes No -
04 Motor encoder adjustment carried out
(p1990 = 1)
Yes No -
05 Motor encoder manually adjusted Yes No -
15 Motor equivalent circuit diagram parameters
changed
Changed Not changed -
r3925[0...n] Identification final display / Ident final_disp
VECTOR Can be changed: - Calculated: - Access level: 3
Data type: Unsigned32 Dynamic index: DDS, p0180 Func. diagram: -
P-Group: Motor Units group: - Unit selection: -
Not for motor type: - Expert list: 1
Min Max Factory setting
- - -
Bit field: Bit Signal name 1 signal 0 signal FP
00 Complete calculation of motor/control
parameters carried out
Yes No -
02 Motor data identification carried out at
standstill (p1910 = 1)
Yes No -
03 Rotating measurement carried out (p1960 =
1 or 2)
Yes No -
04 Motor encoder adjustment carried out
(p1990 = 1)
Yes No -
10 Automatic parameterization only for V/f con-
trol (r0108.2 = 0)
Yes No -
15 Motor equivalent circuit diagram parameters
changed
Changed Not changed -
